Page 1: Controls
Owner’s manual & Installation manual Mode d’emploi et manuel d’installation Manual de instrucciones y de instalación VRX835 Clarion Co., Ltd. All Rights Reserved. Copyright © 2002: Clarion Co., Ltd. QC-6800K 2002/12 (A·C) 280-7943-00... -
Page 2: Table Of Contents
Thank you for purchasing the Clarion VRX835. ∗ This owner’s manual is for the VRX835. ∗ Please read this owner’s manual in its entirety before operating this equipment. ∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment). - Page 3 5. DISPLAY The Color LCD Display and the Information Panel on the main unit show the following displays, provid- ing information about the mode and functions operated. Information Panel Preset channel indication Disc number indication *The disc numbers corresponding to the discs in the CD or MD or DVD changer light.
- Page 4 3. CONTROLS / Main unit / With the Display closed / [ VOL ] [ TILT ] [ OPEN ] [ DISP ] [ RELEASE ] [ ISR ] [ SENSOR ] [ DIRECT ] [ SEARCH ] [ BAND ] [ FUNC ] With the Display open / [ M.LOCK ]...
-
Page 5: Color Lcd Display
Color LCD Display •Radio/TV mode Î WEST COAST (User title) PROGRAM •CD/CD changer mode Î SHINE (User title) USER TITLE •CD TEXT mode Î SHINE (Disc title) DISC TITLE Î Time has come (Track title) TRACK TITLE Î Time has come (Artist) ARTIST •MD changer mode Î... -
Page 6: Outline Of Button And Touchkey Operation When The Display Is Open
OUTLINE OF BUTTON AND TOUCHKEY OPERATION WHEN THE DISPLAY IS OPEN ∗1 ∗1: An example screen indication in the radio mode ∗2: Press an operation button to switch the screen. The operation button is [FUNC] button in the description of operation per mode. ∗3: Touch the screen and the menu correspond- ing to the play mode is displayed. - Page 7 Z-ENHANCER ∗6 ∗7 TYPE 2 VTR N/P NTSC VRX835...
-
Page 8: Remote Control
7. REMOTE CONTROL Remote control unit Operating range: 30˚ in all directions Signal transmitter Inserting the Batteries 1. Turn the remote control unit over, then slide the rear cover in the direction of the arrow. 2. Insert the AA (SUM-3, IECR-6/1.5V) batter- ies that came with the remote control unit facing in the directions shown in the figure, then close the rear cover. -
Page 9: Functions Of Remote Control Unit Buttons
Functions of Remote Control Unit Buttons Mode Radio Button 1 FUNC Switches among radio, CD, DVD, CD changer, MD changer, DVD changer, TV and VISUAL. Power OFF; Press and hold for 1 second or longer. 2 BAND Switches reception DISC UP band. -
Page 10: Dcp
8. DCP The control panel can be detached to prevent theft. When detaching the control panel, store it in the DCP (DETACHABLE CONTROL PANEL) case to prevent scratches. We recommend taking the DCP with you when leaving the car. Removing the DCP 1. -
Page 11: Cautions On Handling
9. CAUTIONS ON HANDLING LCD panel/Generalities For a longer service life, be sure to read the following cautions. • Be sure to store the LCD panel inside the main unit when parking the car outdoors for long period of time. The LCD panel will oper- ate properly in a temperature range of 0 to 60˚C. -
Page 12: Operations
10. OPERATIONS Basic Operations CAUTION When the unit is turned on, starting and stop- ping the engine with its volume raised to the maximum level may harm your hearings. Be careful about adjusting the volume. Note: • Use this unit after starting the engine. ACC or engine ON position Turning on and off the power... -
Page 13: Basic Operations
Basic Operations Showing a mode display When the panel is open: Touch the menu screen switching touchkey when the main screen is being displayed to show the menu screen. Touch the Title List Select key (--- SELECT) on the menu screen to show the Title List display. In the Title List display, the titles of items stored in the [DIRECT] buttons 1 to 6 are listed. - Page 14 Basic Operations Turning the liquid crystal panel horizontal (Air conditioner operation mode) When the way the liquid crystal panel is mounted hinders the operation of the air condi- tioner, the position of the panel can be turned horizontal temporarily. 1. Press and hold the [OPEN] button when the liquid crystal panel is upright, and release the button when a beep is heard.
- Page 15 Basic Operations screen to return to the AUDIO-MODE screen. Touch the [RTN] key on the AUDIO-MODE screen to return to the STANDARD display. ∗ To return from the Z-Enhancer level mode display to the STANDARD display, press the [A-M] button once again. Adjusting the bass and treble Notes: •...
-
Page 16: Radio Operations
Radio Operations FM reception For enhanced FM performance the ® tuner includes signal actuated stereo control, Enhanced Multi AGC, Impulse noise reduction curcuits and Multipath noise reduction circuits. Changing the reception area This unit is initially set to outside USA frequency intervals of 9kHz for AM and 50kHz for FM. -
Page 17: Manual Memory
Radio Operations Manual memory 1. Press the [BAND] button and select the de- sired band. (FM or AM) 2. Select the desired station with seek tuning, manual tuning, or preset tuning. 3. Press and hold one of the [DIRECT] buttons for 2 seconds or longer to store the current station into preset memory. -
Page 18: Cd Operations
CD Operations Loading a CD 1. Insert a CD into the centre of the insertion slot with the label side facing up. The CD plays automatically after loading. Notes: • Never insert foreign objects into the CD insertion slot. • If the CD is not inserted easily, there may be an- other CD in the mechanism or the unit may re- quire service. -
Page 19: Displaying Cd Titles
CD Operations Scan play The scan play locates and plays the first 10 sec- onds of each track on a disc automatically. This function continues on the disc until it is can- celled. ∗ The scan play is useful when you want to select a desired track. -
Page 20: Visual Operations
VISUAL Operations This function is available when a VTR, etc. is connected to the visual 1 or visual 2 terminal. ∗ The visual 1 mode is not available when a DVD changer is connected to the visual 1. WARNING For your safety, the driver should not watch the VTR, etc. -
Page 21: Cd/Md Changer Operations
VISUAL Operations Notes: • When a normal 4:3 size image, not being a wide one, is viewed by displaying it fully on a wide moni- tor display in a wide mode or a full-wide mode, a part of the peripheral image will be lacking or de- formed. -
Page 22: Selecting A Cd
CD/MD Changer Operations Switching disc titles and track titles (MD) This unit can display disc titles and track titles already entered on MDs. Titles up to 256 char- acters long can be displayed by scrolling the titles. ∗ Titles cannot be entered for MDs with this unit. When the panel is closed: 1. -
Page 23: Repeat Play
CD/MD Changer Operations Fast-forward/Fast-backward GFast-forward Press and hold the right side (d) of the [SEARCH] button for 1 second or longer. ∗ When the panel is open, the same operation is also available by using the [d] button in the panel. -
Page 24: Dvd Changer Operations
CD/MD Changer Operations Random play The random play selects and plays individual tracks on the disc in no particular order. This function continues automatically until it is can- celled. 1. Touch the [SUB MODE] key in the MENU display to show SUB MODE. When you touch the [TRACK RANDOM] key, random play starts. -
Page 25: Dvd Changer Operation
DVD Changer Operation 1. Press the [BAND] button. 2. Each time you press the [BAND] button, the disc changes to the next disc. DVD-Video Operation Skipping a chapter(searching) About chapter Chapter means a small segment to divide the data area of the disc. 1. -
Page 26: Repeat Playback
DVD Changer Operation Repeat playback This operation plays back one track recorded on the video CD repeatedly. 1. Press the [RPT] button. 2. Press the [RPT] button again and repeat playback is turned off. ∗ If you are playing a disc with PBC and the PBC function is engaged, this operation cannot be performed. -
Page 27: Tv Operations
DVD Changer Operation Track scan playback This operation plays back all files recorded on the disc, about 10 seconds for each. 1. Press the [SCN] button. 2. Press the [SCN] button again and scan play- back is turned off. Folder scan playback This operation plays back the first files of all folders on the MP3 disc, about 10 seconds for each. -
Page 28: Seek Tuning
TV Operations Seek tuning 1. Press the [BAND] button and select the de- sired TV band (TV1 or TV2). ∗ If “MANU” is lit in the display (or when the panel is closed, if the indicator “ lit), press and hold the [BAND] button for 1 second or longer. -
Page 29: Other Functions
TV Operations 1. Touch the [SUB MODE] key in the MENU display, the [PRESET SCAN] key appears in the display. Touch the [PRESET SCAN] key to start pre- set scan. 2. When the desired channel is received, touch the [PRESET SCAN] key again. ∗... -
Page 30: Setting The Beep
Other Functions 3. Touch the [TITLE INPUT] key in the MENU display. Touch the [INPUT] key in the USER TITLE display, the display switches to the title input mode display. 4. Touch the characters, symbols, etc. shown in the display to input titles. “←, →”... -
Page 31: Dsp Operations
This unit requires special wiring to mute the au- dio signal automatically when a cellular tele- phone rings in the car. ∗ This function is not compatible wiht all cellular telepones Contact your local authorized Clarion dealer for information on proper installation and compatibility. DSP operations... - Page 32 DSP operations G Woofer out adjustment Select woofer output out of “STEREO”, “MONO”, or “OFF”. Touch the select a desire item key to set it. G Woofer LPF adjustment Select woofer LPF slope out of “50Hz”, “80Hz”, “120Hz”. Touch the select a desire item key to set it. G HPF adjustment Select HPF slope out of “50Hz”, “80Hz”, “120Hz”, or “OFF”.
- Page 33 DSP operations 2. Touch the [z] key to select “POSI. DETAIL”. Touch the [POSI. DETAIL] key to show Posi- tion Detail adjusting display. 3. Touch the [w] or [z] key to adjust to a de- sired fader. Adjusting range of the fader: front 9/rear 9 4.
- Page 34 DSP operations Standard mode/DSF operations DSF effect ON/OFF ∗ The factory default setting is “ON”. 1. Press the [A-M] button to show the AUDIO- MODE display. 2. Touch the [DSF ON/OFF] key to select “on” and “off”. 3. Each time the [ON/OFF] key is touched, the on and off statuses are switched alternately.
- Page 35 DSP operations 4. After the setting, press the [A-M] button again or touch the [RTN] key to return to the STANDARD display. Note: • If the VSE effect is set to OFF, the adjustment made in “VSE operations” is not reflected in the music source.
- Page 36 DSP operations Calling P.EQ BASIC Pattern/USER Pattern 1. Press the [A-M] button to show the AUDIO- MODE display. 2. Touch the [z] key to select “P.EQ BASIC” and “P.EQ USER” mode. Touch the [P.EQ BASIC] and [P.EQ USER] key to show BASIC pattern selecting display or USER pattern selection/memory display.
-
Page 37: Dvd Deck (Video) Operations
DVD Deck (video) Operations DVD deck (video) functions When an optional DVD deck (DVS9755z) is connected through the CeNET cable. In this case, this unit only provides a part of the DVD deck functions. As for other operations not written in this manual, operates with a remote control unit provided with your DVD deck. -
Page 38: In Case Of Difficulty
11. IN CASE OF DIFFICULTY Problem Power does not Fuse is blown. turn on. (No sound is pro- duced.) Incorrect wiring. Nothing happens The microprocessor has when buttons are malfunctioned due to noise, pressed. etc. Display is not ac- curate. The remote con- Direct rays of the sun fall on troller does not... - Page 39 Problem Cause The image is not The parking brake is not displayed. pulled. The display is The brightness control is too dark. low. The operating condition is not good. The headlight of the vehicle is lit. The color of the The color is not adjusted ad- display is light or equately.
-
Page 40: Error Displays
12. ERROR DISPLAYS If an error occurs, one of the following displays is displayed. Take the measures described to eliminate the problem. Error Display ERROR 2 A CD is caught inside the CD deck and is not ejected. ERROR 3 A CD cannot be played due to scratches, etc. -
Page 41: Output
13. SPECIFICATIONS FM Tuner Frequency Range: 87.50 MHz to 108.00 MHz Usable Sensitivity: 11 dBf 50dB Quieting Sensitivity: 17 dBf Alternate Channel Selectivity: 75 dB Stereo Separation(1 kHz): 35 dB Frequency Response(±3 dB): 30 Hz to 15 kHz AM Tuner Frequency Range: 531 kHz to 1629 kHz Usable Sensitivity: 25 µV CD player... - Page 42 VRX835...
-
Page 43: Before Starting
BEFORE STARTING 1. This set is exclusively for use in cars with a negative ground 12 V power supply. 2. Read these instructions carefully. 3. Be sure to disconnect the battery “-” termi- nal before starting. This is to prevent short circuits during installation. -
Page 44: General Cautions
1. Do not open the case. There are no user ser- viceable parts inside. If you drop anything into the unit during installation, consult your dealer or an authorized CLARION service centre. CAUTIONS ON INSTALLATION 1. Prepare all articles necessary for installing the main unit before starting. -
Page 45: Main Unit
182 mm Hole Screwdriver Outer escutcheon Notes: 1) Some car models require special mounting kits for proper installation. Consult your Clarion dealer for details. 2) Fasten the front stopper securely to prevent the main unit from coming loose. Instrument panel Hole... - Page 46 I Fixed Mount (TOYOTA, NISSAN and other ISO/DIN equipped vehicles) This unit is designed for fixed installation in the dashboard. If the vehicle is equipped with a factory-installed radio, install the main unit with the parts and screws marked (∗). (Figure 8) If the vehicle is not equipped with a factory-in- stalled radio, obtain an installation kit to install the main unit in the following procedure.
-
Page 47: Removing The Main Unit
REMOVING THE MAIN UNIT 1. When the rear of the main unit has been se- cured with the method shown in Figure 6 un- fasten the special screw. 2. Remove the outer escutcheon. 3. Insert the hook plate between the spring and the universal mounting bracket, fit tab B of the spring into hole A of the hook plate, then Universal mounting bracket... -
Page 48: Wire Connection
WIRE CONNECTION Securely connect to the metal part of the car with a screw, etc. Subwoofer output terminal L+R (RCA) Front audio output (input) terminal L+R (RCA) ∗4 Rear audio output (input) terminal L+R (RCA) ∗4 Reset switch DSP select switch (∗3) VRX835 Black Choke coil... - Page 49 ∗1: Connecting the PHONE MUTE Terminal The lead included with the unit must be connected to the specified position of the vehicle’s con- nector in order to use the “triggered audio mute for cellular telephones” function. ∗2: Use the attached extension lead when necessary. (Provided with this unit) Note : Before making any installation, disconnect the car battery - (negative) cable.
- Page 50 I Connecting the Accessories • Connection to the external amplifier The external amplifier cannot be connected unless the DSP is connected. For detailed information, refer to the instruction manual of the DSP. • Connection to the CCD camera for vehicle The CCD camera for vehicle can be connected to the CCD terminal on the tuner amp unit.
-
Page 51: Sample Systems
SAMPLE SYSTEMS I Sample System 1 VRX835 Tuner Amp Unit CeNET cable (included the TV tuner) CeNET Y-adapter (CCA-519, sold separately) CeNET CD Changer (DCZ625) Front Speakers RCA video cable (sold separately) DVD input VISUAL 1 (TV TUNER) input RCA video cable (included the TV tuner) TV tuner (TTX7504z,... -
Page 52: Rear View Monitor
I Sample System 2 VRX835 Tuner Amp Unit CeNET cable (included the TV tuner) CeNET TV Tuner (TTX7504z, TTX7501z, TTX7503z) CeNET cable (included the DPH910) Digital Sound Processor (DPH910) CeNET cable (included the VCZ625) VRX835 RCA video cable (sold separately) AV Adapter cable (CCA-389, sold separately)
