Summary of Contents for Intermec PW40A
- Page 1 Quick Start Guide PW40A Bluetooth Printer...
-
Page 2: Packing List
International Charger for Mobile Computer batteries ONLY International Charger for Workboard and Mobile Computer Supplies Replacement Li-Ion 7.2 volt 1.35 mAhr Battery Thermal paper 130’/roll, 50/case Cleaning Card Part Number 226-469-002 Part Number 851-060-102 851-060-104 Part Number 320-081-122 815-034-015 320-066-013 PW40A Printer Quick Start Guide... -
Page 3: Getting Started
Getting Started DC power jack Battery packs Scan trigger access opening PW40A Printer Quick Start Guide Paper roll RJ-11 port Paper advance wheel Paper release lever Charge LED: Green- - ready, Red- - battery low Self-Test button Optional Card reader... -
Page 4: Before Using Your Printer For The First Time
S The printer battery charges in about 3 hours. S Depending on the charger you are using, you can charge the mobile computer battery, workboard battery or both. Center battery support posts Battery pack Battery contact protective tab strips (removed) PW40A Printer Quick Start Guide... - Page 5 If the battery is good, you will see the abbreviation for the word “GOOD” next to the Battery voltage print out. This printer has a built in low battery detector. When the print- er’s battery voltage is low, the printer beeps three times, indicat- ing a Low Battery Warning.
-
Page 6: Paper Loading
Out of Paper The PW40A Printer sounds two quick beeps when it runs out of paper. If the printer is out of paper, the printer suspends opera- tion until paper is present and the lever is down. The printer continues to communicate with the mobile computer as long as it does not “time out.”... - Page 7 6 Push down the paper release lever and insert the paper into the paper well with it resting in the paper rod clips. 7 Press the red button while the printer is on and it will feed paper. You will need about 2 inches of paper coming out of the mechanism.
-
Page 8: Printer Self Test
“LOC” shows whether a font is Resident (R) or Downloaded (D). “CPI” shows characters per inch. “DESCRIPTION” describes the graphic. “NAMES” give the “Easy Print” name, the Line Printer name, and the hexadecimal equivalent of that name. PW40A Printer Quick Start Guide... -
Page 9: Replacing The Battery
3 Push down on the battery near the battery lock tabs. 4 Charge the new battery. Battery removal tabs (one on each side) PW40A Printer Quick Start Guide Center battery support posts Battery packs... -
Page 10: Using Your Printer
The following tables show the LED and audible read alert descriptions. Card Reader LED Indicators Indicates Green Good read Read failed, try again, if it continues to fail call Intermec Technical Support (1-800-755-5505) for assistance PW40A Printer Quick Start Guide... - Page 11 Future releases of the PW40A will have Bluetooth capability. Serial/Wireless Mode The PW40A comes to you as a serial mode printer (No IrDA on a workboard printer) Performing the self-test indicates the current mode of the print- er.
- Page 12 As part of the implementation of the serial port service, this ser- vice refreshes itself every five minutes. That refresh sends a mes- sage to the printer, which then wakes up and causes the beep while resynchronizing with the serial port service. The printer then goes back to sleep based on its timeout.
-
Page 13: Maintenance And Troubleshooting
If the printer is out of paper (or the paper release lever is in the up position) this condition interrupts a batch of receipts, and the printer suspends operation until the condition is fixed. The... -
Page 14: Print Is Too Light
A cable may also be damaged if it is bent at sharp angles. 6 Use only the recommended battery pack for the printer. 7 Printer will not print on wrong side of paper. Re-load if nec- essary. Print Roller Appears Dirty Clean Your Printer. -
Page 15: Using A Cigarette Lighter Adapter
Pull out the fuse. If the elements in the fuse appear broken, replace the fuse. Programming Problems Refer to the Intermec Portable Printers Technical Reference Manu- al (p/n: 978-018-001) Section 4 for more details OR call the Intermec Technical Support 1-800-755-5505 for assistance. -
Page 16: Printer Specifications
Easy Print Protocol for Bar Codes, Stored Graphics, Rotated Fonts. Li Ion 1350 mAh (1 or 2 packs) +5 to +122_F (-15 to +50_C) Internal, intelligent, automatic 4 Meg One year, includes print head. Ex- tended warranty available. PW40A Printer Quick Start Guide... -
Page 17: Global Services And Support
Web Support Visit our web site http://www.intermec.com to download many of our current manuals in PDF format, utilize our technical knowl- edge base ‘Knowledge Central’ or to request technical support. -
Page 18: Product Warranty
(1) year from date of shipment. This one year warranty applies to the PW40A Printer only. The warranty on the battery pack is 90 days from date of shipment. - Page 19 PW40A Printer Quick Start Guide...
- Page 20 Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com e 2002-2006 by Intermec Technologies Corporation. All rights reserved. PW40A0B140 Printer Quick Start Guide *962-018-020C* P/N 962-018-020C...
