Issues and Solutions (continued)
Issue
Label is partially
printed, or the
printout is offset on
the label.
All or most fields of
the printed label are
out of position.
36
Solution
You need to re-calibrate the ZSim program every
time you load a new type or size of media. You
may also need to change the Default Start Adjust
or Default Stop Adjust values.
To calibrate ZSim
1 Press Setup to enter the Configuration menu.
2 Press F1 or F3 until you reach Calibrate.
3 Press Enter.
4 Press Setup or F2 to leave the Configuration
menu.
To calibrate ZSim on the PD41
• Press and hold the Print key more than 1
second but less than 4 seconds.
To calibrate ZSim on the PB50
1 Press Setup to enter the Configuration menu.
2 Press .
Check the value of the Sim Resolution setting.
