Using the Feed/Pause Button

Preparing the Printer for Installation

EasyCoder 4420 and 4440 Bar Code Label Printer User's Manual
C d
The Feed/Pause button, located on the front panel of the 4420 or 4440
printer, performs several functions depending on the mode of the printer.
Feed/Pause Button Functions
Printer Mode You Want To
Idle Feed out one label or
a minimum specified
amount of media.
Continuously feed
media.
Take the printer
offline.
Printing Pause the printer.
Cancel the current
print job.
Turned on for Print the hardware
the first time
configuration test
label.
Before connecting the printer to your data collection system, you need to
1 connect the printer to a power source.
2 open the printer.
3 load media.
4 load ribbon.
5 print a hardware configuration test label.
These steps are described in the next sections.
39
Helvetica CondenseChapter 1 — Getting Started
What to Do
Press and release the Feed/Pause button.
Press and hold the Feed/Pause button.
When you release the button, the media
stops feeding.
Press the Feed/Pause button twice. Press
the button again to bring the printer
online.
Press and release the Feed/Pause button.
Press and release the button again to
resume printing.
Press and hold the Feed/Pause button
until the printer stops printing.
Press and hold the Feed/Pause button.
See "Printing the Hardware
Configuration Test Label" later in this
chapter.
