Install The Parallel I/O Card In The 3Xxx Printer - Intermec EasyCoder 3240 Instruction Sheet

Caution
Static electricity can damage electronic components as you handle them. Static-
sensitive electronic components are packaged in static protective bags. Before
opening the bag, touch it to the metal base of the printer to reduce static electricity.
Touch the metal base of the printer to reduce static electricity before installing the
parallel I/O card in the printer.
1. Turn off the printer power and remove the power cord.
2. Remove the media cover and the electronics cover from the printer.
3. Remove and discard the optional I/O board port cover from the rear of the printer
(see illustration). Retain the two port cover screws.
Optional I/O
board port
Retain the
two screws
Optional
I/O board
port cover
3XXI005.eps
