Intermec EasyCoder 101 User Manual page 51

Intermec ActiveX Controls are ready-to-run components that you can use to print bar
codes from Windows Microsoft Office or other popular Windows applications. Using
Intermec Active X Controls to print bar codes provides the following advantages:
Uses resident printer bar code symbologies.
Provides configurable properties, such as symbology, text, font, and orientation.
Eliminates the need for additional applications, bar code fonts, or add-on tools.
Inserts scannable bar codes into documents by sending EasyCoder command
language sequences to the printer, not bit-mapped graphical data.
Enables the printer to deliver high throughput while maintaining excellent print
quality.
Uses fixed data, serialized data, data from a database, or data through a
programming interface.
To learn more about ActiveX controls, see your application user's manual.
1. Start Microsoft Word .
2. From the File Menu, select Print. In the Printer name list box, select the EasyCoder
printer. Click OK.
3. From the Insert menu, select the Object command.
4. Select Intermec ActiveX Bar Code from the Object type list box. Click OK. The
Intermec ActiveX Bar Code is inserted into your Word document.
5. Change the bar code properties.
a. Double click on the bar code. The Properties screen appears. Edit the properties
of the bar code.
b. When finished, click OK. The changes take effect immediately.
6. Print the label.
4
