Intermec EasyCoder 101 User Manual page 13

4. Select a directory for the AXIS Print Monitor (the default location is recommended)
and click OK.
The IP Installer is used by EasyCoder IPL printers only.
1. Uninstall any existing AXIS IP Installer files. (From the Windows Start menu, open
Programs and select Intermec AXIS Communications / IP Installer. Click on the
uninstall program and follow the screen prompts to complete the uninstall tasks.)
2. Locate the new AXIS IP Installer on your hard drive or Printer Companion CD. The
files have been compressed into a self-extracting zip file for easy downloading. The
filename is Setup_IPInstaller.exe.
3. Double-click on the self-extracting file to unzip and install the utility.
4. Follow the installation prompts to install the IP Installer in the default directory
(C:\Program Files\AXIS Communications\IP Installer) and create a Program icon
group at AXIS Communications\IP Installer.
5. When the installation is complete, click Finish.
Select one of the following methods to assign an IP address to the printer:
Use the AXIS IP Installer (for EasyCoder IPL printers only).
Use the ARP method to send DOS commands to the printer (for all EasyCoder
printers).
Note: The AXIS Ethernet adapter installed in your EasyCoder printer requires a specific
IP address and not a dynamically assigned one. If your network dynamically assigns IP
addresses to network devices, consult with your network administrator.
This method can be used to assign an IP address only to an EasyCoder IPL printer.
1. From the Windows Start Menu, select Programs. Select the IP Installer from the
AXIS program group.
2. For the IP Installer to have access to the Ethernet printer you are installing, you
must cycle the power on the EasyCoder printer. The method you will use depends
on the type of AXIS Ethernet adapter that is installed in your printer.
