Windows 95, 98, and NT

Although the AXIS Print Monitor user dialog varies slightly between
Windows 95, 98, and NT, the functionality is exactly the same.
To install an Ethernet adapter for a Windows 95, 98, or NT network
Note: The AXIS Print Monitor needs to be installed on each
workstation performing peer-to-peer printing. The AXIS Print Monitor
is not needed on the client platforms for client/server printing.
1. Start the Add Printer Wizard by selecting Settings then Printers
from the Start Menu and double-clicking on the Add Printer icon.
2. Select Local Printer (Windows 95 and 98) or My Computer
(Windows NT).
3. Click OK.
4. Follow the rest of the Add Printer Wizard's instructions to perform
the remaining steps of the installation process.
If you want to install a printer to a new LPR port, refer to the Intermec
Ethernet Adapter User's Manual (Part No. 068749).

Windows 3.1 and Windows for Workgroups

For peer-to-peer printing, all Windows 3.1 and Windows for
Workgroups users requiring access to a network printer need to install
the AXIS Print Utility for Windows onto their workstations. Peer-to-
peer printing does not require a file server and is recommended for
smaller networks.
Client/server printing is suitable for larger networks and requires only
one user to install the AXIS Print Utility for Windows software onto
their workstation.
Note: Windows 3.1 requires network support such as LAN Server or
LAN Manager Workstation software to be installed in order to redirect
a local printer port to a network device.
Note: AXIS Print Utility for Windows must be running when you print
through your Ethernet adapter. We recommend that you copy the AXIS
Print Utility icon into your StartUp file.
