Summary of Contents for Intermec 6808
-
Page 2: Packing List
6808CR 40- Column Printer Quick Start Guide Packing List Check to ensure that you receive these items: Intermec R R R R 6808CR Printer p/n 320-081-007 Compliance Statement Product Warranty Card... - Page 3 Power Adapters AC Power Adapter (110 volt) U.K. Power Supply Europe Power Supply Australian Power Supply Cigarette Lighter Adapter, 5 Amp. 6 in. coiled 6808 Single Charger Supplies Replacement Li--Ion 1350mAhr Battery Thermal Paper 130’/roll, 50/case Part Number 320-081-022 320-081-023...
-
Page 4: Getting Started
6808CR 40- Column Printer Quick Start Guide Getting Started Here are the main components of the Intermec Self-Test button Charge indicator Paper release lever RJ-11 port 6808CR Printer Components 6808CR print- Paper tear bar Battery packs Ribbon cartridge IrDA window (side panel) -
Page 5: Before Using Your Printer For The First Time
Before Using Your Printer For The First Time Remove the protective tab strips underneath the batteries. They are placed there to keep your printer from self-charging during shipment. 1. Lift the battery up before pulling on the tabs. If you pull... - Page 6 6808CR 40- Column Printer Quick Start Guide Table 1-1(continued) Print-out Explanations Self Test Description Paper 1 or 2 ply Beeper May be turned On or Off. Batt Volt Current voltage of the battery pack. Batt Temp Temperature of the battery.
- Page 7 IrDA compliant printer, regardless of the other features that each device offers. Intermec printers come from the factory with the IrDA trans- mission speed rate set at 38.4 kbits and no wait. This is the recommended setting and allows the printer to receive and print data at the same time.
-
Page 8: Charging The Lithium Ion Batteries
The 6808CR uses one or two batteries (VBATT1 and VBATT2). This printer has a built in low battery detector. When the printer’s battery voltage is low, the printer beeps three times, indicating a Low Battery Warning. This only happens if the printer is awake. -
Page 9: Paper Loading
Out of Paper The 6808CR Printer sounds two quick beeps when it runs out of paper. If the printer is out of paper, the printer suspends op- eration until paper is present and the lever is down. The print- er continues to communicate with the mobile computer as long as it does not “time out.”... - Page 10 6. Push down the paper release lever and insert the paper into the paper well with it resting in the paper rod clips. 7. Press the red button while the printer is on and it will feed paper. You will need about 2 inches of paper coming...
-
Page 11: Using Your Printer
1. Attach the mobile computer to printer cable. RJ-11 cable p/n 321-578-001 2. As you use the printer the power comes from the battery in the printer. When the printer battery runs down the printer will not operate until the battery is recharged. -
Page 12: Maintenance And Troubleshooting
Maintenance and Troubleshooting Cleaning the Interior Dirt, adhesive and residue collect on the print head of the printer and need to be removed. Clean your printer once a month if you use it frequently, or once every three months if used infrequently. -
Page 13: Troubleshooting
If the printer is out of paper (or the paper release lever is in the up position) this condition interrupts a batch of receipts, and the printer suspends operation until the condition is fixed. The printer continues to communicate with the mobile computer as long as it does not “time out.”... -
Page 14: Print Roller Appears Dirty
Paper Options button. Adjust the Dark- ness setting to a higher percentage until the print is dark and crisp. Refer to the Intermec Portable Printers Technical Refer- ence Manual (p/n: 978-018-001) Section 4 for more details. -
Page 15: Specifications
6808CR 40- Column Printer Quick Start Guide Specifications Table 1-6 Printer Specifications Specs 6808 CR Dimension 6.56 x 6.81 x 3.34 in. (172 x 167 x 85.5 mm) Weight: 25.2 oz. (714 g) Print Method: Direct thermal Print Medium: Thermal paper, linerless Paper Width: 4.40 in. - Page 16 6808CR 40- Column Printer Quick Start Guide Table 1-6 (continued) Printer Specifications Specs 6808 CR Drop Test: Four feet to concrete Warranty: One year, includes print head. Extended warranty available. *962018017*...
