Summary of Contents for Intermec 6820

  • Page 1 Installation Instructions 6820 Printer...
  • Page 2 The information contained herein is provided solely for the purpose of allowing customers to operate and service Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec Technologies Corporation.
  • Page 3: Table Of Contents

    Installing the Printer ..............16 Fixed Mount Printer P/N 709-850-006 Mounting Plate (Optional) ......16 Wall Mount Printer Kits .
  • Page 4: Global Services And Support

    Note: Notes either provide extra information about a topic or contain spe- cial instructions for handling a particular condition or set of circumstances. Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec web site at Web Support Visit the Intermec web site at documents (in PDF).
  • Page 5: Telephone Support

    Technical Support Service Service contracts Outside the U.S.A. and Canada, contact your local Intermec representative. To search for your local representative, from the Intermec web site, click About Us > Contact. 6820 Printer Installation Instructions Description • Place an order.
  • Page 6 Gunpo-si, Gyeonggi-do Korea, South 435-776 Contact: Mr. Sinbum Kang Telephone: +82-31-436-1191 Email: IN Information System Ptd LTD 6th Floor Daegu Venture Center Bldg 95, Shinchum 3 Dong Donggu, Daegu City, Korea Email: sbkang@awoo.co.kr jmyou@idif.co.kr OR korlim@gw.idif.co.kr Global Services and Support 6820 Printer Installation Instructions...
  • Page 7: Using The Installation Kit

    P/N 203-242-101 (Fixed Mount and Wall Mount Printers) P/N 203-242-102 (Portable Printers). The 6820 Printer and associated electrical wiring should be installed under the supervision of properly trained and qualified personnel. Follow these installation instructions to ensure safe, reliable performance of the 6820 Printer.
  • Page 8: Installing The Direct-To-Battery Cable

    Excess electrical noise can be severe enough to defeat the electrical filtering that is built into Intermec cables, printers, and vehicle docks. Defective ignition wiring, damaged insulation, or a faulty vehicle electrical component can cause electrical noise —...
  • Page 9: Preparing The Vehicle Battery Cable

    • Secure the vehicle battery cable at least every 18” (50 cm) throughout the cable run: use adjustable clamps (provided) or wire-tie to existing vehicle cable runs. • Completely install the printer power cable and take voltage measurements before connecting the printer. Preparing the Vehicle Battery Cable...
  • Page 10: Connecting To The Vehicle Battery

    2 Screw a 3/8” nut as far as it will go onto a 3/8” x 1-1/2” bolt furnished in kit, then slip a 3/8” washer onto the bolt. 3 Slide the positive (red wire with fuse link) terminal ring from the printer power cable onto the bolt.
  • Page 11 3 Reinstall the positive battery cable, then tighten the nut securely. 4 Slip a 3/8” washer onto the extended end of each bolt. 5 Slide the positive (fuse link with red wire) terminal ring from the printer power cable onto the positive (+) battery bolt.
  • Page 12 9.52 mm (0.37 in) nut 9.52 mm (0.37 in) x 1- 12.7 mm (0.50 in) bolt 9.52 mm (0.37 in) washer (2 places) Fuse holder 6820 Printer Installation Instructions Vehicle battery cable...
  • Page 13: Connecting To A Two Battery Vehicle System

    Securing the Vehicle Battery Cable To secure the vehicle battery cable 1 Secure the vehicle battery cable every 18” (50 cm) with adjustable cable clamps. Work from the battery to the mounting area for the printer. 6820 Printer Installation Instructions Correct Connection Method...
  • Page 14: Grounding The Printer Power Cables

    Grounding the Printer Power Cables The printer power cable has a ground strap that must fasten to vehicle sheet-metal to ensure proper cable shielding. This ground strap is the wire with a ring terminal by the white connectors between the DC power cable and the vehicle battery cable.
  • Page 15: Verifying The Printer Power Cable Voltage

    Verify the printer power cable voltage and polarity (as indicated), then plug the printer DC power cable into the printer power connector. Use a volt meter to test the cable before connecting the cable to the 6820 Printer. Set the voltmeter for DC volts.
  • Page 16: Installing The Printer

    The angle mounting plate and printer footprint are for the fixed mount printers. Note the keyholes cut into the bottom of the oversize paper tray. These keyholes allow you to install or remove the fixed mount printer from a vehicle without using any special tools. Sliding latches in the tray bottom hold the printer securely Note: Nuts and bolts are not provided.
  • Page 17 Once you select where to install the fixed mount printer in the vehicle, you permanently install the plate. The following angle mounting plate has access holes where necessary so special tools are not required for securely tightening hardware. 19.0 cm (7.32 in)
  • Page 18 The following flat mounting plate has access holes where necessary so special tools are not required for securely tightening hardware. 31.5 cm (12.4 in) 34.3 cm (13.5 in) 2.3 cm (0.9 in) Flat Mounting Plate (P/N 709-966-006) 6820 Printer Installation Instructions...
  • Page 19: Wall Mount Printer Kits

    803-041-000 754-546-002 754-548-002 Flat paper tray The 714-417-001 Mounting Plate also includes a 5” x 4” plate adapter bracket and knob. 6820 Printer Installation Instructions Description Flat Paper Tray Mounting Plate 6 1/4” - 20 1/2” bolts (3 needed) 6 1/4” split washers...
  • Page 20: Contents Of Compact Paper Tray - P/N 203-489-001

    Contents of Compact Paper Tray - P/N 203-489-001 Part Number 650-447-001 801-194-003 803-041-000 Description Compact Paper Tray 2 1/4” - 20 1/2” bolts 2 1/2 split washers 650-447-001 Compact paper tray 6820 Printer Installation Instructions...
  • Page 21 You need a space that is 17” x 26” x 13” (43 cm x 66 cm x 33 cm) for the mounting plate, wall mount printer, and flat paper tray. 6820 Printer Installation Instructions 43 cm (17 in) 66 cm...
  • Page 22 17” x 22” x 7” (43 cm x 56 cm x 18 cm) is required for the mounting plate, wall mount printer, and compact paper tray. 43 cm (17 in) 56 cm (22 in) 18 cm (7 in) 6820 Printer Installation Instructions...
  • Page 23: Installing The Mounting Plate

    Installing the Mounting Plate The mounting plate for the wall mount printer hangs on the wall of a vehicle. Install the plate with the knob screw on top and the mounting lips facing outward. Use four bolts, evenly distributed, to secure the plate to the vehicle wall.
  • Page 24: Attaching Either Paper Tray To The Mounting Plate

    2 Hold either paper tray in place and insert two 1/4”-20 x 1/2” bolts (with 1/2” split washers) in the holes, through the paper tray. Use a 7/16” wrench to tighten the bolts. Center lip on flat paper tray Bottom lip on mounting plate 6820 Printer Installation Instructions Center lip on compact paper tray...
  • Page 25: Mounting The Printer

    Mounting the Printer The wall mount printer sits on the bottom lip of the mounting plate. The top of the printer is held to the plate via a 5” x 4” plate adaptor bracket and a knob. To mount the printer 1 Using the two slots on the printer bottom, push the printer onto the two bottom lips on the mounting plate.
  • Page 26: Printer Installation Instructions

    Everett, Washington 98203 Everett, Washington 98203 U.S.A. U.S.A. tel 425.348.2600 tel 425.348.2600 fax 425.355.9551 fax 425.355.9551 www.intermec.com www.intermec.com © © 2006 Intermec Technologies 2007 Intermec Technologies Corporation. All rights reserved. Corporation. All rights reserved. 6820 Printer Installation Instructions *931-052-001* P/N 931-052-001...
