- Page 1 Quick Start Guide 681/682/781T/782 40-Column Printers...
-
Page 2: Packing List
681/682 and 781T/782 Printer Quick Start Guide Packing List Check to ensure that you receive these items: Intermec 681 Printer p/n 320-082-00x Intermec 781T Printer p/n 320-085-00x Compliance Statement Intermec 682 Printer p/n 320-083-00x Intermec 782 Printer p/n 320-084-00x with card reader p/n 320-084-003... - Page 3 681/682 and 781T/782 Printer Quick Start Guide Common Accessories Sold Separately AC Wall Charger Mobile Computer to PrinterCable p/n 851-060-002 Order power cord under p/n 226-469-001 (RJ-45 connector separate part number on the printer end) p/n 321-578-001 (RJ-11 connector on the printer end)
-
Page 4: Getting Started
681/682 and 781T/782 Printer Quick Start Guide Getting Started Here are the main components of the Intermec printers. Charger Jack Printer Case Open 681/781T Printer Components Terminal Holder Computer Securing Tab Ribbon (Dot Matrix) Paper Advance Charge LED (red charging;... -
Page 5: Charging The Lithium Ion Batteries
681/682 and 781T/782 Printer Quick Start Guide Charging the Lithium Ion Batteries The printer battery charges in about 3 hours. " You can charge both the Mobile Computer and the Printer " battery at the same time using the AC or Cigarette Light- er Charger. - Page 6 681/682 and 781T/782 Printer Quick Start Guide Beep Indicators Number of Beeps Indicates A) Printer has come out of sleep mode. B) Using the 781T with wireless printing, the radio when enabled but not put in use for a while beeps every five minutes to let you know it is enabled and also using battery life.
-
Page 7: Using Your Printer
681/682 and 781T/782 Printer Quick Start Guide Using Your Printer Intermec 681 or 781T Printer 1. Attach the Mobile Computer to Printer cable. RJ-11 cable p/n 321-578-001, RJ-45 cable p/n 226-469-001 2. As you use the printer the power comes from the battery in the printer. -
Page 8: Using The Card Reader
681/682 and 781T/782 Printer Quick Start Guide Using the Card Reader Slide the card down into the reader with the magnetic tape to the right side. The magnetic card must meet the following ISO standards: 7810 (physical characteristics) 7811 (recording tech-... - Page 9 681/682 and 781T/782 Printer Quick Start Guide 781T Printer using Wireless Printing IrDA/Wireless Mode Your printer comes to you as an IrDA mode printer. To switch the mode to Wireless Printing it is necessary to toggle the mode via the self-test function of the printer.
- Page 10 681/682 and 781T/782 Printer Quick Start Guide 700 Mobile Computer Preparation 1. On your mobile computer, tap the Bluetootht icon located in the System tray on the Today screen. 2. Select Advanced Features>Bluetooth Devices. 3. From the Tools menu, select Device Discovery. You are presented with a couple of screens detailing the device dis- covery process.
- Page 11 681/682 and 781T/782 Printer Quick Start Guide 9. The Bluetooth Serial Port service is necessary for the virtual COM port to work. Choose COM6 in your applica- tion to use the Wireless Printing device you selected. Verify that this service was discovered by looking at the properties for this printer (Device>Properties).
-
Page 12: Battery Pack Removal
681/682 and 781T/782 Printer Quick Start Guide Battery Pack Removal Ensure that you have your ESD wrist strap connected to the ESD static free mat before placing your printer on the mat and begin removing the battery pack. 1. Remove the four screws securing the printer mechanism. - Page 13 681/682 and 781T/782 Printer Quick Start Guide 3. Set the printer assembly down to view the underside of printer mechanism and battery compartment. Printer assembly wire cluster 4. Remove the four screws securing the battery cover. Avoid contact with the printer control board unless the board is grounded.
- Page 14 681/682 and 781T/782 Printer Quick Start Guide 5. Gently disconnect the keyed battery pack connector (with the black and red wires) from the board assembly. You may find that you have to wiggle the connector a bit to remove it from the connector.
- Page 15 681/682 and 781T/782 Printer Quick Start Guide 7. Insert the new battery pack into the battery cover. 8. Reinstall the battery cover. 9. Reconnect the keyed battery cable. Routing the battery pack wires is very important. The wires must not be pinched or crimped when reinsert- "...
-
Page 16: General Specifications
681/682 and 781T/782 Printer Quick Start Guide General Specifications Temperatures Operating: Thermal 781T Dot Matrix Storage: Thermal Dot Matrix Wireless Printing Radio Option: Operating: Continuous Operation off charge: Thermal (over 8 hours) Dot Matrix (over 4 hours) Charging: 2--3 hours quick charge using AC adapter or ciga-...
