- Page 1 Installation Instructions 6820 Printer...
- Page 2 The information contained herein is provided solely for the purpose of allowing customers to operate and ser- vice Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec Technologies Corporation.
-
Page 3: Table Of Contents
Mount the Printer ......... . 13 6820 Printer Installation Instructions... -
Page 4: Global Services And Support
Global Services and Support Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec web site at www.intermec.com and click Service & Support. The Inter- mec Global Sales & Service page appears. From the Service & Support menu, move your pointer over Support, and then click Warranty. -
Page 5: Installation Kit
203-242-101 (Fixed Mount and Wall Mount Printers) 203-242-102 (Portable Printers) The 6820 Printer and associated electrical wiring should be installed under the supervision of properly trained and qualified personnel. Follow these installation instructions to ensure safe, reliable performance of the 6820 Printer. -
Page 6: Vehicle Electrical System
— possibly causing unpredictable behavior in printers and docks. Electrical Installation Decide where to mount the 6820 Printer and vehicle dock, then follow these instructions. Power Cable Routing • Cable Length: A shorter printer dc power cable connects the printer to the vehicle bat- tery cable, extending the overall cable length. -
Page 7: Direct-To-Battery Cable Installation
• Secure the vehicle battery cable at least every 18” (50 cm) throughout the cable run: use adjustable clamps (provided) or wire-tie to existing vehicle cable runs. • Completely install the printer power cable and take voltage measure- ments before connecting the printer. 6820 Printer Installation Instructions... -
Page 8: Prepare The Vehicle Battery Cable
4 Crimp the red wire onto the fuse link. 3/8” terminal ring Black (or brown) wire Strip the wire, then install the terminal ring Fuse link Vehicle battery cable Crimp here Fuse link assembly Red wire P/N: 236-107-001 6820 Printer Installation Instructions... -
Page 9: Connect To The Vehicle Battery
7 Repeat steps 2-6 for the negative vehicle battery cable wire (black or brown), hooking up the negative cable to the negative battery terminal. Vehicle battery 3/8” nut 3/8 x 1-1/2” bolt Vehicle battery cable 3/8” washers Fuse holder 6820 Printer Installation Instructions... -
Page 10: Secure The Vehicle Battery Cable
2 Remove the paper backing from a clamp (P/N: 807-059-001) and stick the clamp in place while drilling a pilot hole with a #26 drill bit. Use #6 sheet-metal screws to permanently hold clamps in place. #6 sheet-metal screw goes here 6820 Printer Installation Instructions... -
Page 11: Ground The Printer Power Cables
Verify the printer power cable voltage and polarity (as indicated), then plug the printer dc power cable into the printer power connector. Use a volt meter to test the cable before connecting the cable to the 6820 Printer. Set the voltmeter for dc volts. -
Page 12: Mechanical Installation
Top view of latch Side view of latch Unlatch Note: Nuts and bolts are not provided. You must locally select and pur- chase hardware that provides the most secure installation possible for the application and vehicle. 6820 Printer Installation Instructions... - Page 13 The following flat mounting plate has access holes where necessary so spe- cial tools are not required for securely tightening hardware. Top view Side view 12.4” (31.5 cm) 0.9” (2.3 cm) 13.5” (34.3 cm) Flat Mounting Plate (P/N: 709-966-006) 6820 Printer Installation Instructions...
-
Page 14: Wall Mount Printer Kits
The 714-417-001 Mounting Plate also includes a 5” x 4” plate adapter bracket and knob. With Compact Paper Tray - 203-489-001 Part Number Description 650-447-001 Compact Paper Tray 801-194-003 2 1/4” - 20 1/2” bolts 803-041-000 2 1/2 split washers 650-447-001 Compact Paper Tray 6820 Printer Installation Instructions... -
Page 15: Dimensions With Flat Paper Tray
7” (18 cm) below for paper tray Mounting Plate 7” (18 cm) 17” x 22” x 7” (43 cm x 56 cm x 18 cm) is required for the mounting plate, wall mount printer, and compact paper tray. 6820 Printer Installation Instructions... -
Page 16: Install The 714-417-001 Mounting Plate
2 Hold either paper tray in place and insert two 1/4”-20 x 1/2” bolts (with 1/2” split washers) in the holes, through the paper tray. Use a 7/16” wrench to tighten the bolts. Center lip on flat paper tray Compact paper tray Center lip on mounting plate 6820 Printer Installation Instructions... -
Page 17: Mount The Printer
Knob screw on mounting Knob plate assembly Plate adaptor bracket Wall Mount Printer Bottom lips on mounting plate assembly Bottom of printer This illustration assembly is using the Flat Paper Tray. 6820 Printer Installation Instructions... - Page 18 Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com 6820 Printer Installation Instructions *962-018-016D* P/N 962-018-016D...
