Chapter 1: Before You Begin
Conventions Used in This Manual
To help you learn how to use your GR8, the manual uses these symbols and typographical conventions:
Convention
!
CAUTION
UP ARROW
CAPITAL LETTERS
BACK ARROW

Assembling the GR8

The GR8 is shipped with the control module and mounting
bracket packed separately.
steps:

Attaching the Control Module

1. The hardware to attach the control module's mounting
bracket to the GR8 is installed on the top of the charger.
There are three bolts with one fl at washer, one lock wash-
er, and one hex nut per bolt. Remove the washers and hex
nuts, and set them aside.
Midtronics Inc. 7000 Monroe Street
Table 2: Symbols And Typographical Conventions
The safety symbol indicates instructions for avoiding hazardous conditions and personal injury.
The word CAUTION indicates instructions for avoiding equipment damage.
The wrench symbol indicates procedural notes and helpful information.
The text for keypad buttons are in Bold capital letters.
The text for screen options are in regular capital letters.
The text for soft keys are in Bold capital letters.
For easy assembly, follow these
One of three
pre-installed
bolts for the
control module
mounting
bracket.
Willowbrook, IL 60527
Description
2. Center the three holes in mounting bracket over the bolts,
and lower the bracket onto the charger. Reinstall the hard-
ware in this order: the fl at washer fi rst, the lock washer
next, and the hex nut last. Tighten the nuts securely.
10
GR8-1200 OEM
One of four pre-installed bolts
on the bracket for mounting the
control module.
