Thermo Scientific Shandon ClearVue A79210100 Operator's Manual page 9

3 3
4 4
10 10
6 6
17 17
1. Load Door
2. Unload Door
3. Access Door
4. Touch Screen
5. Mountant bottle
6. Load Rail
7. Xylene Tray
8. Unload Rail
9. Downdraft Ventilation
10. Coverslip Preparation Area
11 11
11. Debris Tray Door
12. Filter Cover
13. Main Power Switch, Fuses and Connector
14. 3½" Floppy Disk Drive
15. Rating Label
16. Vents for Electronics Enclosure
17. battery Isolation Switch
Shandon ClearVue™ Operator Guide
12 12
16 16
15 15
14 14
1 - Load Door 1 - Load Door
2 - Unload Door 2 - Unload Door
3 - Prep Door 3 - Prep Door
4 - Touch Screen 4 - Touch Screen
5 - Mountant Bottle 5 - Mountant Bottle
6 - Load Rail 6 - Load Rail
7 - Xylene Tray 7 - Xylene Tray
8 - Unload Rail 8 - Unload Rail
9 - Downdraft Ventilation 9 - Downdraft Ventilation
10 - Prep Area 10 - Prep Area
11 - Debris Tray Access Door 11 - Debris Tray Access Door
12 - Filter Cover 12 - Filter Cover
13 - Mains Power Switch and Connector 13 - Mains Power Switch and Connector
14 - 3½" Floppy Disk Drive 14 - 3½" Floppy Disk Drive
15 - Rating Label 15 - Rating Label
16 - Vents for Electronics Enclosure 16 - Vents for Electronics Enclosure
17 - Battery Isolation Switch 17 - Battery Isolation Switch
13 13
A79210100 - Iss 2 9
