INSTALLATION and OPERATION MANUAL
End Suction Centrifugal Pumps
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notification.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
BARNES
BARNES
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Model: 4030HCC
Form No. 052318-Rev. K
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Crane Barnes 4030HCC
Summary of Contents for Crane Barnes 4030HCC
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notification. A Crane Co. Company...
-
Page 2: Table Of Contents
Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems, Inc 1984, 1997, 1998, 2002, 10/04, 4/06, 8/06 Alteration Rights Reserved... -
Page 3: Safety First
Always wear appropriate safety gear, such as safety IMPORTANT! - Crane Pumps & Systems, Inc. is not glasses, when working on the pump or piping. responsible for losses, injury, or death resulting from a... -
Page 4: Pump Specifications
SECTION: A - PUMP SPECIFICATIONS: SUCTION/DISCHARGE . 4” (102mm) Suction, 3” (76mm) SEAL: Design ..Single Mechanical Discharge, 125 lb Flange. Lubrication..Self-Lubrication Discharge can be placed in 8 Material ..Rotating Faces - Carbon defferent locations depending on Stationary Faces - Ni-Resist piping requirements Elastomer - Buna-N LIQUID TEMPERATURE 180°F (82°C) Continuous... -
Page 5: General Information
(3), and pull volute (1) from seal plate (15). The impeller (8), Service Department in Piqua, Ohio, telephone (937) 778-8947 screw (9) washer (10) wear rings (6) and (11) and o-ring (13) or Crane Pumps & Systems Canada, Inc., in Bramton, Ontario are now exposed for examination or replacement. (905) 457-6223. -
Page 6: Replacement Parts
When stationary member (12B) needs replaced, remove cap F-1 ORDERING REPLACEMENT PARTS: screws (18), lockwashers (19), and pull seal plate (15) from When ordering replacement parts, ALWAYS furnish the bearing housing (17). Press used stationary member (12B) following information: from seal plate. 1. -
Page 7: Trouble Shooting
TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. SYMPTOM POSSIBLE CAUSE(S) Little or no discharge 1. Casing not filled with water 1. -
Page 10: Parts List
PARTS KIT Seal Kit ....P/N: 083562 (‡) 6, 12, 13, 14, 16. PARTS LIST Model: 4030HCC P/N: 059461 ITEM QTY. PART No. DESCRIPTION 059452 Volute 016409 Stud 1/2-13 x 2.00” Lg 002608 Lockwasher 1/2” 15-6-6 Hex Nut 1/2-13, Zp 003217 Pipe Plug 1/4”... -
Page 11: Returned Goods Policy
Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material.
