Page 1
Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notification. A Crane Co. Company...
START-UP REPORT ......................39 - 40 Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems, Inc 1995,1997,1998,1/2004, 4/05 , 1/06, 3/06, 9/06, 12/06, 2/07...
IMPORTANT! - Crane Pumps & Systems, Inc. is not responsible for losses, injury, or death resulting from a WARNING! - DO NOT pump hazardous materials failure to observe these safety precautions, misuse or (flammable, caustic, etc.) unless the pump is specifically...
Inc., Service Department in Piqua, Ohio, telephone (937) mounting brackets and locate the base elbow on the bottom 778-8947 or Crane Pumps & Systems Canada, in Brampton, of the wet well. Level the base elbow with grout and/or Ontario, (905) 457-6223.
Page 5
B-3) Liquid Level Controls: The cord assembly mounted to the pump must not be It is recommended to use a liquid level control system modified in any way except for shortening to a specific that allows the on and off point to be separated by at least application.
Page 15
THREE PHASE 460-575 VOLT AC (orange molded plug) THREE PHASE 460-575 VOLT AC (orange molded plug) MOISTURE AND TEMPERATURE SENSORS MOISTURE AND TEMPERATURE SENSORS Power Cable Power Cable Motor Lead ID Motor Lead ID Power Cable Power Cable Lead ID Lead ID Green (Ground) Green...
Page 16
TYPICAL POWER CIRCUIT FIGURE 3b Single Phase Cap Chart Cap Kit Start Relay Start Cap Run Cap 1750 133042 Mars 64 440MFD @ 330V 50MFD @370V 3450 1750 141361 Mars 64 297MFD @ 330V 40MFD @440V 1750 Single Phase Start Components...
Page 17
TYPICAL THERMAL PROTECTION WIRING DIAGRAM FIGURE 4 B-4.3) Overload Protection: B-4.4) Moisture Sensors: Current sensing overloads must be provided in the pump A normally open (N/O) detector is installed in the pump seal control panel and should be properly sized for the full load chamber, which will detect any moisture present, and a current of the pump.
FIGURE 5 B-5) When Used with a Variable Speed Drive: C-2.1) Incorrect Rotation for ThreD-Phase Pumps: Maximum turndown should not exceed 2:1. Drive should be In the event that the rotation is incorrect for a threD-phase set to operate in constant torque mode. installation, interchange any two power cable leads at the control box.
C-3.2) Insulation Test: E-1) Lubrication Before the pump is put into service, an insulation (megger) E-1.1) Checking Oil 1. Place pump on it’s side, and drain oil into a clean, dry test should be performed on the motor. The resistance values container.
Page 20
E-2) Impeller and Volute Service: E-2.1) Disassembly and Inspection: To clean out the volute (11), or clean out or replace impeller (6), disconnect power, remove cap screws (2) then vertically lift motor assembly from the pump body (11). Clean out the volute, if necessary, clean and examine impeller (6) for pitting or wear, replace if required.
SECTION: F REPLACEMENT PARTS F-1 ORDERING REPLACEMENT PARTS: When ordering replacement parts, ALWAYS furnish the following information: 1. Pump serial number and date code. (Paragraph F-4) 2. Pump model number. (Paragraph F-3) 3. Pump part number. (Paragraph F-2) 4. Part description. 5.
TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH “CAUSE”...
Page 28
“A” Impeller– Vortex “B” Impeller– Vortex Trim Dia. Ductile Iron Nihard Trim Dia. Ductile Iron Nihard mm (in) Part No. Part No. mm (in) Part No. Part No. 205mm (8.07in) 125454B 143272B 185mm (7.28in) 125456 143273 200mm (7.87in) 125454BTA 143272BTA 180mm (7.09in) 125456TA 143273TA...
Page 29
“R” Impeller “PA” Impeller Trim Dia. Ductile Iron Nihard Trim Dia. Ductile Iron Nihard mm (in) Part No. Part No. mm (in) Part No. Part No. 175mm (6.89in) 133050 143285 205mm (8.07in) 137223 143288 170mm (6.69in) 133050TA 143285TA 200mm (7.87in) 137223TA 143288TA 165mm (6.50in)
Page 30
Leg Kits Leg Kit includes: Leg Kit Leg Kit Height • 3 Legs (painted) Model Part No. Inches (mm) • attachement hardware 3XSHVC 125506 3.15 (80) 3XSHVR 125506 3.15 (80) 3XSHVRA 125506 3.15 (80) 3XSHMPA 125506 3.15 (80) 4XSHMS 125506 3.15 (80) 4XSHDF 125506...
Page 31
Seal Kit includes: Volute Kit includes: • Volute O-Ring (option 1) • Wear Ring (as needed)(pressed) • Volute O-Ring (option 2) • Volute (painted) • Volute O-Ring (option 3) • External Retaining Ring NOTE: Kit contains hardware your pump may not require. Hardware Kit includes: Impeller Attachment Kit includes: •...
Reliance Electric), Effluent and Sump pump models are Warranted for sixty (60) months (or 10,000 hours of operation) from the date of manufacture from Crane Pumps & Systems to the End Purchaser as follows: Crane Pumps &...
Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material.
A Crane Co. Company START-UP REPORT General Information Pump Owner’s Name: __________________________________________________________ Address: ____________________________________________________________________ Location of Installation: _________________________________________________________ Contact Person: __________________________________Phone: _______________________ Purchased From: _____________________________________________________________ Nameplate Data Pump Model #: ___________________ Serial #: _____________________________________ Part #: __________________________ Impeller Diameter: ____________________________ Voltage: _________ Phase: _____ Ø...
Page 40
( ) Engineer: ____________________________ ( ) Operator: ________________________ ( ) Contractor: ____________________________ ( ) Other: ___________________________ All parties should retain a copy of this report for future trouble shooting/reference A Crane Co. Company 420 Third Street 83 West Drive Piqua, Ohio 45356 Brampton, Ont.
