INSTALLATION, OPERATION & MAINTENANCE MANUAL
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notifi cation.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
DEMING
DEMING
Sump Pump
Series: 4507
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
2, 3, 4 & 6 Foot
Form No. 120013-Rev. F
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Crane DEMING 4507 Series
Summary of Contents for Crane DEMING 4507 Series
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notifi cation.
-
Page 2: Safety First
Other brand and product names are trademarks or registered trademarks of their respective holders. Deming® is a registered trademark of Crane Pumps & Systems, Inc. 1996, 10/06 Alteration Rights Reserved... - Page 3 Systems Service Department in Piqua, Ohio, telephone rotation. Pull the bearing from the shaft. Follow the (937) 778-8947 or Crane Pumps & Systems Canada, Inc., reverse procedure to reassemble. Bramton, Ontario, (905) 457-6223.
- Page 4 D - ASSEMBLY Assemble suction head strainer (316) to casing (1). Assemble motor support (19) and casing (1) to column Assemble base (53) to suction head strainer (316). pipe (101). Setscrews (520) should not be turned too tightly because casing will have to be turned later to Place coupling spider on lower half of coupling.
- Page 5 Item No. Description Casing Impeller Shaft * 18 Ball Bearing Frame Base Plate * 24 Impeller Nut Impeller Key Bearing Cover * 39 Bottom Bearing Bushing * 39A Int. Bearing Bushing Coupling Coupling Key Base Shaft Adjusting Nut Lock Washer Int.
- Page 7 Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material.
- Page 8 A Crane Co. Company START-UP REPORT General Information Pump Owner’s Name: __________________________________________________________ Address: ____________________________________________________________________ Location of Installation: _________________________________________________________ Contact Person: __________________________________Phone: _______________________ Purchased From: _____________________________________________________________ Nameplate Data Pump Model #: ___________________ Serial #: _____________________________________ Part #: __________________________ Impeller Diameter: ____________________________ Voltage: _________ Phase: _____ Ø...
- Page 10 Notes...
