INSTALLATION, OPERATION & MAINTENANCE MANUAL
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notifi cation.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
DEMING
DEMING
Vertical Process Pumps
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Series:
4310 & 4311
Form No. 120007-Rev. E
Advertisement
Related Manuals for Crane Deming 4310 Series
Summary of Contents for Crane Deming 4310 Series
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notifi cation.
-
Page 2: Safety First
(fl ammable, caustic, etc.) unless the pump is specifi cally designed and designated to handle them. Other brand and product names are trademarks or registered trademarks of their respective holders. Deming® is a registered trademark of Crane Pumps & Systems, Inc. 1996, 9/06 Alteration Rights Reserved... -
Page 3: A) General Information
(24) then unscrew impeller (2) turning it Systems Service Department in Piqua, Ohio, telephone counter-clockwise while holding shaft (6) with (937) 778-8947 or Crane Pumps & Systems Canada, Inc., wrench. Bramton, Ontario, (905) 457-6223. b. On 3” pumps, unscrew impeller lock nut (24) - Page 4 C. For shaft inspection. 1. Check shaft (6) for wear and out of roundness. F - LOCATING TROUBLE 2. Check length of shaft extension beyond motor fl ange. 3. If shaft is worn, remove two set screws (211) and pull 1.
- Page 5 Fig. 4310 Size: 1”, 1½ and 2” ITEM No. DESCRIPTION ITEM No. DESCRIPTION Casing Seal Impeller Shaft Bearing Shaft Set Screws Impeller Nut Cap Screws Defl ector Pipe Plug Shaft Key Cap Screws Adapter Motor Casing Gasket...
- Page 6 Fig. 4310 Size: 3” ITEM No. DESCRIPTION ITEM No. DESCRIPTION Casing Seal Impeller Shaft Bearing Shaft Set Screws Impeller Nut Cap Screws Impeller Key (Woodruff) Pipe Plug Defl ector Cap Screws Shaft Key Motor Adapter Impeller Washer Casing Gasket Pipe Plug...
- Page 7 Limited 24 Month Warranty Crane Pumps & Systems warrants that products of our manufacture will be free of defects in material and workmanship under normal use and service for twenty-four (24) months after manufacture date, when installed and maintained in accordance with our instructions.This warranty gives you specifi c legal rights, and there may also be other rights which vary from state to state.
- Page 8 Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material.
