Menu 10 parameters

Status and diagnostic information
Trip log
Braking control
Parameter
10.01 Drive healthy indicator
10.02 Drive running indicator
10.03 At zero speed indicator
10.05 Below set speed indicator
10.06 At speed indicator
10.07 Above set speed indicator
10.11 Braking active indicator
10.12 Braking-resistor overload alarm indicator
10.15 ac supply loss indicator
10.17 {0.39} Motor [I2t] overload alarm indicator
10.18 Heatsink temperature alarm indicator
10.19 Alarm indicator
10.20 {0.44} Last trip
10.21 Second last trip
10.22 Third last trip
10.23 Fourth last trip
10.24 Fifth last trip
10.25 Sixth last trip
10.33 Drive reset
10.38 User-defined trips
10.39 {0.42} Internal braking-resistor overload accumulator
10.40 Status word
10.41 Trip-0 time (years, days)
10.42 Trip-0 time (hours, minutes)
10.43 Trip-1 time (hours, minutes)
10.44 Trip-2 time (hours, minutes)
10.45 Trip-3 time (hours, minutes)
10.46 Trip-4 time (hours, minutes)
10.47 Trip-5 time (hours, minutes)
10.52 SLM technology failure indicator
10.53 Under-voltage protection disable
10.54 AC-supply phase failure protection disable
10.55 Internal braking-resistor protection disable
10.56 {0.41} Drive overload accumulator
10.57 Supply interlock
2
10.58 {0.40}
Motor I t accumulator
10.59 SLM pcb temperature
10.60 Motor winding temperature
M'Ax User Guide
Issue Number: 4
Range( ) Default(
ô
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 255
0 ~ 100.0 %
0 ~ 32767
0.000 ~ 9.365 y.d
00.00 ~ 23.59 h.m
00.00 ~ 600.00 h.m
00.00 ~ 600.00 h.m
00.00 ~ 600.00 h.m
00.00 ~ 600.00 h.m
00.00 ~ 600.00 h.m
0 ~ 512
0 ~ 1
0 ~ 1
0 ~ 1
0.0 ~ 100.0 %
0 ~ 1
0.0 ~ 100.0 %
0 ~ 100 ° C
0 ~ 220 ° C
*
Type
)
ð
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Txt S P
RO Txt S P
RO Txt S P
RO Txt S P
RO Txt S P
RO Txt S P
RO Bit
0 RW Uni
RO Uni P
RO Uni P
RO Uni P
RO Uni S P
RO Uni S P
RO Uni S P
RO Uni S P
RO Uni S P
RO Uni S P
RO Uni P
0 RO Bit P
0 RO Bit
0 RW Bit
RO Uni P
RO Bit P
RO Uni P
RO Uni P
RO Uni P
