Control Techniques M'Ax 403 User Manual page 78

*
Parameter
8.01 Digital input 1 state indicator
8.02 Digital input 2 state indicator
8.03 Digital input 3 state indicator
8.04 Digital input 4 state indicator
8.05 Digital input 5 state indicator
8.06 Digital input 6 state indicator
8.07 Digital input 7 state indicator
8.08 Digital input 8 state indicator
8.09 {0.01} Hardware enable indicator
8.11 Digital input 1 invert
8.12 Digital input 2 invert
8.13 Digital input 3 invert
8.14 Digital input 4 invert
8.15 Digital input 5 invert
8.16 Digital input 6 invert
8.17 Digital input 7 invert
8.18 Digital input 8 invert
8.20 Digital-inputs read-word
Digital input 1 destination selector
8.21
(RUN)
Digital input 2 destination selector
8.22
(REVERSE SELECT)
Digital input 3 destination selector
8.23
(JOG FORWARD)
Digital input 4 destination selector
8.24
(FORWARD LIMIT)
Digital input 5 destination selector
8.25
(REVERSE LIMIT)
Digital input 6 destination selector
8.26
(RESET)
Digital input 7 destination selector
8.27
(Preset reference select bit-0)
Digital input 8 destination selector
8.28
(Preset reference select bit-1)
8.51 Digital output 1 state indicator
8.52 Digital output 2 state indicator
8.53 Digital output 3 state indicator
8.54 Digital output 4 state indicator
8.55 Status-relay state indicator
8.59 Status line indicator
8.60 Status line output enable
8.61 Digital output 1 invert
8.62 Digital output 2 invert
8.63 Digital output 3 invert
8.64 Digital output 4 invert
8.65 Status-relay invert
Digital output 1 source selector
8.71
(DRIVE RUNNING)
Digital output 2 source selector
8.72
(AT ZERO SPEED)
Digital output 3 source selector
8.73
(ALARM)
Digital output 4 source selector
8.74
(AT SPEED)
Status-relay source selector
8.75
(DRIVE HEALTHY)
72
Range( ) Default(
ô
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1 0
0 ~ 1 0
0 ~ 1 0
0 ~ 1 0
0 ~ 1 0
0 ~ 1 0
0 ~ 1 0
0 ~ 1 0
0 ~ 16384
00.00 ~ 20.50
6.34
menu.parameter
00.00 ~ 20.50
6.33
menu.parameter
00.00 ~ 20.50
6.31
menu.parameter
00.00 ~ 20.50
6.35
menu.parameter
00.00 ~ 20.50
6.36
menu.parameter
00.00 ~ 20.50
10.33
menu.parameter
00.00 ~ 20.50
1.45
menu.parameter
00.00 ~ 20.50
1.46
menu.parameter
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1 0
0 ~ 1 0
0 ~ 1 0
0 ~ 1 0
0 ~ 1 0
00.00 ~ 20.50
10.02
menu.parameter
00.00 ~ 20.50
10.03
menu.parameter
00.00 ~ 20.50
10.19
menu.parameter
00.00 ~ 20.50
10.06
menu.parameter
00.00 ~ 20.50
10.01
menu.parameter
) Type
ð
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RW Bit
RW Bit
RW Uni
RW Bit
RW Bit
RW Uni
RW Bit
RW Bit
RO Uni P
RW Uni P
RW Uni P
RW Uni P
RW Uni P
RW Uni P
RW Uni P
RW Uni P
RW Uni P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit P
RO Bit
RO Bit
RW Bit
RW Bit
RW Bit
RW Bit
RW Bit
RW Uni P
RW Uni P
RW Uni P
RW Uni P
RW Uni P
M'Ax User Guide
Issue Number: 4
