Serial comms. baude rate
0.36
{11.25} (see below)
ô
RW Txt S P
Baud rate
300
600
1200
2400
4800
9600 Default
19200
See Appendix C Serial Communications.
Serial comms. address
0.37
{11.23} 0.0 ~ 24.7
ô
RW Uni P
See Appendix C Serial Communications.
Initial parameter displayed selector
0.38
{11.22} 00.00 ~ 21.51
ô
RW Uni P
Version _AN
Use 0.38 to specify the parameter whose value is to be displayed on the
upper line of the alphanumeric keypad when the Drive is powered-up;
this is termed the initially displayed parameter. By default, parameter
0.05 Speed feedback is the initially displayed parameter.
Normally only one of the Menu 0 parameters can be specified as the
initially displayed parameter. If 0.35 User security code is set at 0 , any
parameter can be specified.
Version _SL
0.38 has no effect.
2
Motor [I t] overload alarm indicator
0.39
{10.17} 0 ~ 1
ô
RO Bit P
0.39 indicates 1 when both the following conditions arise:
• Motor current exceeds 110% of the rated motor current
• The value in the overload accumulator in the SLM exceeds 75%
Version _ AN : The lower line of the alphanumeric display indicates the
alarm OuL .
If the motor current is not reduced, the Drive will trip due to excessive
motor current (trip code: I2t.AC ).
2
Motor I t accumulator
0.40
{10.58} ô 0.0 ~ 100.0
RO Uni
0.40 indicates the value of a motor thermal-overload accumulator in the
Drive that monitors the power delivered to the motor. If the value reaches
100%, the lower line of the alphanumeric display (version _ AN ) indicates
the alarm OuL (the Drive continues controlling the motor). If the value
exceeds 100%, the Drive will trip; the display then indicates I2t.AC .
48
0.41
{10.56}
9600
ð
RO
BAUD
0.41 indicates the value of an I
power of the Drive. If the value exceeds 100%, the Drive will trip; the
lower line of the alphanumeric display (version _ AN ) then indicates
O.ht1 .
0.42
{10.39}
RO
0.42 indicates the value of the of an I
power dissipated in the internal braking resistor. If the value exceeds
100% (representing 150W), the Drive trips; the lower line of the
alphanumeric display (version _ AN ) indicates It.br .
ð 1.1
GROUP.UNIT
0.43
{5.05}
RO
0.42 indicates the value of the DC-bus voltage.
0.05
ð
0.44
MENU.PARAMETER
{10.20}
RO
0.44 indicates the trip code of the last trip.
0.45
{11.56}
RO
0.45 indicates 1 when
0.46
0.46 can be assigned to any advanced parameter and given a scaling
factor. A typical use would be indicating the rate of flow in a way that is
meaningful to the production process (e.g. cans per hour).
The default function is as follows:
0.01 x [0.05] Speed feedback
See Optional setting-up in Chapter 6 Setting Up the Drive for Basic
Applications.
0.47
{11.39}
RO
%
0.48
{11.29}
RO
Drive overload accumulator
0.0 ~ 100.0
ô
Uni P
2
t accumulator that monitors the output
Internal braking-resistor overload accumulator
0 ~ 100.0
ô
Uni P
2
t accumulator that monitors the
DC-bus voltage
ô 0 ~ 1000
Uni P
Last trip
Txt S P
SLM communications integrity
0 ~ 100
ô
Uni
)
t echnology data links are operating correctly.
Programmable parameter
SLM software version
00.99 ~ 99.99
ô
Uni P
Drive software version
1.00 ~ 99.99
ô
Uni P
%
%
V
