Parameter
2.01 Post-ramp reference
2.02 {0.24} Ramp enable
2.03 Ramp hold enable
2.04 {0.27} Fast ramp select
2.06 S-ramp enable
2.07 S-ramp acceleration limit
2.10 Acceleration rate selector
2.11 {0.25} Acceleration rate 1
2.12 Acceleration rate 2
2.13 Acceleration rate 3
2.14 Acceleration rate 4
2.19 Jog acceleration rate
2.20 Deceleration rate selector
2.21 {0.26} Deceleration rate 1
2.22 Deceleration rate 2
2.23 Deceleration rate 3
2.24 Deceleration rate 4
2.29 Jog deceleration rate
2.32 Acceleration-rate select bit-0 indicator
2.33 Acceleration-rate select bit-1 indicator
2.35 Deceleration-rate select bit-0 indicator
2.36 Deceleration-rate select bit-1 indicator
2.46 Stop-control proportional-gain
2.47 Stop-control integral-gain
2.48 Braking-control proportional gain
2.49 Braking-control integral gain
58
Range( ) Default(
ô
±[1.06]
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
2
0 ~ 300.000 s /1000RPM
0 ~ 5
0 ~ 32.000 s/1000RPM
0 ~ 32.000 s/1000RPM
0 ~ 32.000 s/1000RPM
0 ~ 32.000 s/1000RPM
0 ~ 32.000 s/1000RPM
0 ~ 5
0 ~ 32.000 s/1000RPM
0 ~ 32.000 s/1000RPM
0 ~ 32.000 s/1000RPM
0 ~ 32.000 s/1000RPM
0 ~ 32.000 s/1000RPM
0 ~ 1
0 ~ 1
0 ~ 1
0 ~ 1
1 ~ 200
1 ~ 200
1 ~ 200
1 ~ 200
) Type
ð
RO Bi P
0 RW Bit
0 RW Bit
0 RW Bit
0 RW Bit
0.031 RW Uni
0 RW Uni
0.200 RW Uni
0.200 RW Uni
0.200 RW Uni
0.200 RW Uni
0.200 RW Uni
0 RW Uni
0.200 RW Uni
0.200 RW Uni
0.200 RW Uni
0.200 RW Uni
0.200 RW Uni
0 RO Bit
0 RO Bit
0 RO Bit
0 RO Bit
1 RW Uni
10 RW Uni
50 RW Uni
10 RW Uni
