SUPPLIED ACCESSORIES

Supplied accessories is described in the IC-PCR1500's In-
struction manual.

SPECIFICATIONS

Specifications is described in the IC-PCR1500's Instruction
manual.

OPTIONS

UT-106*
DSP UNIT
Provides AF DSP functions such as noise reduction and auto notch.
CP-12L
CIGARETTE LIGHTER CABLES
For operation and charging via a 12 V cigarette lighter socket.
OPC-254L
DC POWER CABLES
For operation and charging via an external power supply.
SP-10
EXTERNAL SPEAKER
For all-round mobile operation. Cable length: 1.5 m; 4.9 ft
OPC-1156
SEPARATION CABLE
For extended separate installation. 3.5 m; 11.5 ft
*: UT-106 installation is described in the IC-PCR1500's Instruction
manual.
iii

TABLE OF CONTENTS

FOREWORD ........................................................................................... i
IMPORTANT ............................................................................................ i
EXPLICIT DEFINITIONS ......................................................................... i
PRECAUTIONS ...................................................................................... ii
SUPPLIED ACCESSORIES .................................................................. iii
SPECIFICATIONS ................................................................................. iii
OPTIONS ............................................................................................... iii
TABLE OF CONTENTS ......................................................................... iii
1 CONNECTION .............................................................................. 1-2
■ Rear panel connection .................................................................... 1
■ Antenna installation ........................................................................ 2
2 PANEL DESCRIPTION ................................................................. 3-7
■ Front panel-controller .................................................................. 3
■ Function display-controller ........................................................... 5
■ Rear panel-main unit ................................................................... 7
3 SETTING A FREQUENCY .......................................................... 8-10
■ Turning power ON/OFF ................................................................. 8
■ Mode selection ............................................................................... 8
■ Tuning step selection ..................................................................... 9
■ Setting a frequency ........................................................................ 9
■ Receive mode selection ............................................................... 10
4 BASIC OPERATION ................................................................. 11-15
■ Receiving ..................................................................................... 11
■ Monitor function ............................................................................ 11
■ Lock function ................................................................................ 11
■ Attenuator function........................................................................ 12
■ NB function .................................................................................. 12
■ AGC function ................................................................................ 12
