8

SPECIFICATIONS

D General
• Frequency coverage
• Channel spacing
• Mode
• Number of memory channels : 20
• Acceptable power supply : 13.75* V or 27.5* V DC
(negative ground)
• Usable temp. range
• Frequency stability
• Current drain
(at 13.75 V DC)
Tx
Rx
• Dimensions
(projections not incl.)
• Weight
D Transmitter
• Output power
• Modulation
• Modulation limiting
• Audio harmonic distortion : Less than 10 %
(at 85 % modulation)
• Hum and noise ratio
• Spurious emissions
• Antenna impedance
15
: 118 to 136.975 MHz
: 25 kHz or 25/8.33* kHz
: AM (6K00A3E)
*Automatic selection
: –30˚C to +60˚C
: ±5 ppm
:
5 A (max.)
4 A ( at AF max.)
0.5 A (at STAND BY)
: 150 (W)✕50 (H)✕180 (D) mm
29 31 3
5 / (W)✕1 / (H)✕7 / (D) in
32 32 32
: 1.5 Kg; 3 lb 5 oz
: 36 W (pep) typical
9 W (carrier) typical
: Last Stage modulation
: 70 to 100 %
: More than 40 dB
: –16dBm or less
: Standard 50 Ω with SWR <3
D Receiver
• Receive system
• Intermediate frequencies
•Sensitivity
(at 6dB S/N)
• Squelch sensitivity
(at threshold)
• Selectivity
25 kHz ch. spacing
8.33* kHz ch. spacing
• Spurious response rejc,
• Audio output power
Side tone
• Hum and noise
• Audio output impedance
*Except USA version
All stated specifications are subject to change without
notice or obligation.
: Double conversion
superheterodyne
: 1st 38.85 MHz
2nd 450 kHz
: Less than 1 µV (pd)
: Less than 0.35 µV (pd)
: More than ±8 kHz (at –6 dB)
Less than ±17 kHz (at –40 dB)
Less than ±25 kHz (at –60 dB)
More than ±2.778 kHz (at –6 dB)
Less than ±7.37 kHz (at –60 dB)
: More than 74 dBµ
: More than 10 W (at 13.75 V DC
with 8 Ω load 60 % MOD. 10%
distortion)
More than 100 mW (with 500 Ω
load 60% MOD. 10 % distortion)
: More than 25 dB
: Ext. SP 8 Ω
Side tone 500 Ω
