D DATA SOCKET
DATA
PIN No.
1
DATA IN
2
3
1
2
4
DATA OUT Data out terminal for 9600 bps operation only.
3
4
5
AF OUT
5
6
Rear panel view
6
D ACC SOCKETS
ACC (1)
PIN No. NAME
1
RTTY Controls RTTY keying
2
GND Connects to ground.
3
HSEND Goes to ground when transmitting.
2
4
5
4
MOD
1
3
8
6
7
5
Rear panel view
6
SQLS
7
13.8 V 13.8 V output when power is ON.
8
ALC
ACC (2)
PIN No. NAME
1
8 V
2
GND
3
HSEND
2
4
5
4
BAND
1
3
6
7
5
ALC
Rear panel view
6
VSEND Goes to ground when transmitting.
7
13.8 V
NAME
Input terminal for data transmit. (1200 bps: AFSK/9600 bps: G3RUH, GMSK)
GND
Common ground for DATA IN, DATA OUT and AF OUT.
PTT P
PTT terminal for packet operation. Connect ground to transmit data.
Data out terminal for 1200 bps operation only.
Squelch out terminal. Becomes high (+8 V) when the transceiver receives a signal
which opens the squelch.
P SQL
• To avoid unnecessary TNC transmission, connect squelch to the TNC to inhibit trans-
mission when receiving signals.
• Keep audio output at a normal level, otherwise a "P SQL" signal will not be output.
DESCRIPTION
Input/output pin.
(HF/50 MHz only)
When grounded, transmits.
Modulator input.
Connects to a modulator.
AF detector output.
AF
Fixed, regardless of [AF] position in
default settings. (see notes below)
Squelch output.
Goes to ground when squelch opens.
ALC voltage input.
DESCRIPTION
Regulated 8 V output.
Band voltage output.
(Varies with amateur band)
Input/output pin (144 MHz only)
When grounded, transmits.
PANEL DESCRIPTION
DESCRIPTION
SPECIFICATIONS
"High" level
: More than 2.4 V
"Low" level
: Less than 0.6 V
Output current
: Less than 2 mA
Connected in parallel with ACC(2) pin 2.
Ground level
: –0.5 V to 0.8 V
Output current
: Less than 20 mA
Input current (Tx)
: Less than 200 mA
Connected in parallel with ACC(2) pin 3.
Input impedance
: 10 kΩ
Input level
: Approx. 100 mV rms
Output impedance : 4.7 kΩ
Output level
: 100–300 mV rms
SQL open
: Less than 0.3 V/5 mA
SQL closed
: More than 6.0 V/100 µA
Output current
: Max. 1 A
Connected in parallel with ACC(2) pin 7.
Control voltage
: –4 V to 0 V
Input impedance
: More than 10 kΩ
Connected in parallel with ACC(2) pin 5.
SPECIFICATIONS
Output voltage
: 8 V ±0.3 V
Output current
: Less than 10 mA
Same as ACC(1) pin 2.
Same as ACC(1) pin 3.
Output voltage
: 0 to 8.0 V
Same as ACC (1) pin 8.
Ground level
: –0.5 V to +0.8 V
Output current
: Less than 20 mA
Input current (Tx)
: Less than 200 mA
Same as ACC(1) pin 7.
1
8
