QualGear QG-PRO-PM-SCA2-W Instruction Manual

Suspended deiling adapter

Download this manual

Attaching the 1.5" NPT Pipe to the Suspended Ceiling Adapter

Alley Key

(I)

(F) x 2

(G) x 2

To connect the 1.5" NPT pipe (sold separately) to the ceiling adapter, twist the male threaded

end into the female thread of the adapter. Then secure the position with screws (F or G) using the

allen key (I).

IMPORTANT!

Do not loosen screws

all the way when

making adjustments,

this will disconnect the

parts and may cause

injury or property

damage.

1.5" NPT Pipe

(not included)

QG-PRO-PM-SCA2-W

CAUTION!

27.2kg

Do not exceed the maximum rated weight

(60lbs)

specified. Otherwise, serious injury or

RATED

property damage may occur.

5 Year Limited Warranty

June 2016

Version June 2016

QualGear LLC

Need help?

Do you have a question about the QG-PRO-PM-SCA2-W and is the answer not in the manual?

Page 1 QG-PRO-PM-SCA2-W Attaching the 1.5" NPT Pipe to the Suspended Ceiling Adapter IMPORTANT! Do not loosen screws all the way when making adjustments, this will disconnect the parts and may cause injury or property damage. Alley Key (F) x 2 1.5" NPT Pipe...
Page 2 Before starting installation, please check that all parts shown in this checklist are included. If any parts are missing or damaged, contact your local distributor or support@qualgear.com for replacement parts and do not start assembly and installation WARNING until you receive all the parts.
Page 3 Mounting to a Wooden Joist or Wooden Stud Ceiling Mounting to a Concrete Ceiling Make sure drilled holes are free of dust For concrete ceiling mounting, follow NOTE so the anchors will be set properly. step 1b, and for truss, follow step 1c. Stud Finder drill depth 38mm...
Page 4 Mounting to a Truss Attaching the Joined Ceiling Plates to the Ceiling Truss Truss Suspended Wire Wire (J) Loop wire around the truss and twist around itself several times to secure. Joining the Ceiling Plates Ceiling Plate (B) Nut (L) Turnbuckle Screw (K) Attach the suspended wire from previous step to the turnbuckles (E), then hook the turnbuckles...
