QualGear QG-TM-030-BLK Installation Manual

Installing the Safety Bar and the Padlock

5
Make sure the TV is safely secured before releasing
IMPORTANT:
The folded edge
faces inward.
B
Safety Bar
Insert the safety bar onto the rail (at the bottom of the wall plate) to secure. Put a padlock on
the safety bar to prevent the TV from being stolen.
Padlock is not
included
;
Scan the QR Code™ below
for more info about this product:
QG-TM-030-BLK
For Most 37" to 70" Flat Panel and
70
Curved TVs
40kg
Do not exceed the maximum rated weight
40kg
(88lbs)
specified. Otherwise, serious injury or
(88lbs)
property damage may occur.
3 0 0 x 2 0 0 | 3 0 0 x 3 0 0 | 4 0 0 x 2 0 0
4 0 0 x 3 0 0 | 4 0 0 x 4 0 0 | 6 0 0 x 2 0 0
6 0 0 x 3 0 0 | 6 0 0 x 4 0 0
Version April 2018 Version April 2018
