GENERAL INFORMATION

The EM101 is a small electromagnetic low-flow flowmeter with
chemically-resistant plastic wetted parts and platinum elec-
trodes suitable for use with a variety of chemicals. Capable
of measuring pulsating flows from diaphragm-type metering
pumps, it is designed primarily for electrically-conductive chemi-
cal injection applications. The 1/4" and 3/8" sizes monitor
maximum flows of 1 and 3 gallons per minute (or 4 and 11
L/min), respectively. Barb or NPT fittings are available, and
FEATURES
Captive plastic cover screw (4)
(mounting screws inside)
Backlit LCD display
(16 characters x 2 lines)
Keypad switches, tactile
Polycarbonate housing
Power cord
Connector (2)
for optional output cables
Connector (2)
for sensor cables

SPECIFICATIONS*

Materials Meter housing
Electrodes
O-Ring
Display housing
Rate Display Units
Total Display Units
Power
Accuracy
Max Fluid Temperature
Maximum Pressure
Minimum Conductivity
Outputs
*Specifications subject to change • Please consult our website for current data (www.seametrics.com).

FLOW RANGE

SIZE LOW FLOW CUTOFF
L/MIN GAL/MIN
-025
.04 .01
-038
.11 .03
Fusion coated aluminum
Platinum
Viton™ (EPDM optional)
Polycarbonate
Gal/Minute, Liters/Second, Gal/Hour
Gallons, Liters
115 Vac, 60 Hz
+/-1% of reading,
plus .005 gpm (0.02 lpm)
185˚ F (85˚ C)
150 psi (@ 75˚ F)
>20 microSiemens/cm
• 4-20 mA, 0-5 Volts, both isolated
• Frequency to 9999 pulses per gallon, isolated (10 mA, 30 Vdc)
• High alarm, low alarm relay, isolated (100 mA, 110 Vac/Vdc)
MINIMUM FLOW for spec accuracy
GAL/hR L/MIN
.60 .26
1.80 .76
must be designated at time of order.
The EM101 is 115 Vac, 60 Hz powered and includes a rate
and total display as well as a variety of outputs. For continu-
ous transmission of a flow signal, there is a 4-20 mA output,
a 0-5 volt signal, and a frequency signal proportional to flow.
In addition, there are relay alarm outputs for user-set low and
high flow levels.
Display
Flow
Meter
GAL/MIN GAL/hR
.07 4.2
0.2 12
6 ft. control cables (2)
out to display
Fusion coated
aluminum housing
PVDF plastic fittings (2)
Male NPT or barb
(must be designated at time of order)
10-24 grounding screws
(on bottom of meter)
Removable bracket
for mounting
MAXIMUM FLOW
L/MIN GAL/MIN
3.8 1
11 3
GAL/hR
60
180
