Electric Swing TV Wall Mount
Instruction Manual
SKU: MOUNT-E-WM075
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-e-wm075
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-E-WM075
Summary of Contents for Vivo MOUNT-E-WM075
- Page 1 Electric Swing TV Wall Mount Instruction Manual SKU: MOUNT-E-WM075 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-e-wm075 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete walls. If unsure, please contact us at vivo-us. com, email at help@vivo-us.com, or call us at 309-278-5303.
- Page 3 TOOLS NEEDED Phillips 3/8” Drill Bit Pencil 3/16” Drill Bit Tape Measure Stud Finder Screwdriver Drill ASSEMBLY STEPS STEP 1 Temporarily plug Power Cord (G) into Mount (A) and then into an AC outlet. While holding mounting arm, use Remote (H) to unfold the mounting plate until it is 90 degrees to the arm. Then remove the Power Cord (G).
- Page 4 STEP 2 OPTION A: Wood Stud Installation OPTION B: Concrete/Brick Installation Locate the stud in the wall where you will Place Template (B) on the wall in the desired location and use Level (T-B) to align, and mark mount the assembly. Use of a studfinder is recommended.
- Page 5 STEP 3 Assemble Top Cover (D) and Bottom Cover (E) to Mount (A). STEP 4 Using a Phillips screwdriver, loosen the safety screws on the back of VESA Brackets (C).
- Page 6 STEP 5 Attach the VESA Brackets (C) to the back of the TV using Screws (M-A through M-E), M5-M8 Washers (M-F) and Spacers (M-G, M-H). STEP 6 Hang VESA Brackets (C) over Mount (A). Tighten safety screws on VESA Brackets (C) to secure in place.
- Page 7 STEP 7 Level the TV by adjusting the leveling screws ontop of VESA Brackets (C) using 4mm Allen Wrench (T-A) and Level (T-B). Use Straps (I) to organize cables. STEP 8 Plug Power Cord (G) into Mount (A) and then into an AC outlet. Use Remote (H) to operate. CAUTION: To avoid injury, do not place hand in the arm while operating.
- Page 8 AVG. RESPONSE TIME help@vivo-us.com (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
