- Page 1 Mechanical Arm Single Ultrawide Monitor Wall Mount SKU: MOUNT-V100E Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/mount-v100e...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
-
Page 3: Package Contents
Package Contents A (x1) B (x1) C (x1) Upper Arm Lower Arm Wall Mount D (x1) E (x1) F (x1) VESA Bracket Oval Cap Round Cap... -
Page 4: Included Hardware & Tools
Included Hardware & Tools S-A (x1) S-B (x1) M-A (x4) M-B (x4) M8 Nut M8x35mm M4x12mm M5x12mm Screw Screw Screw M-C (x4) W-A (x3) W-B (x3) W-C (x3) M5 Washer ST6.3x5mm Concrete Anchor M6 Washer Screw T-A (x1) T-B (x1) 4mm Allen 6mm Allen Wrench... - Page 5 STEP 1 Option 1: Wood Stud Mounting Use Wall Mount (C) to mark drilling locations on the wall where a stud is located. Use of a level and stud finder is recommended. Pre-Drilling Instructions Drill mounting holes using illustration below. 3/16”...
- Page 6 Wood Stud Mounting - Cont’d Secure Wall Mount (C) to wall using ST6.3x55 Screws (W-A) with M6 Washers (W-C) and a 10mm socket wrench. Insert Round Cap (F) and Oval Cap (E) into the mounting holes. Do NOT use included Anchors (W-B) for wood or drywall.
- Page 7 STEP 1 - Cont’d Option 2: Concrete / Brick Mounting Pre-Drilling Instructions Drill mounting holes using illustration below. 3/8” (10mm) Drill Bit 2.4” (60mm) Use Wall Mount (C) to mark drilling Hole Depth locations. Use of a level is recommended. Press Concrete Anchors (W-B) into the drilled holes.
- Page 8 STEP 2 Insert Lower Arm (B) into Wall Mount (C). Secure Set screw by tightening using 4mm Allen Wrench (T-A). Set Screw Set Screw Insert Upper Arm (A) into Lower Arm (B). Secure Set screw by tightening using 4mm Allen Wrench (T-A). Set Screw Set Screw...
- Page 9 STEP 3 Secure VESA Bracket (D) to Upper Arm (A) using M8x35mm Screw (S-B), M8 Nut (S-A), and 6mm Allen Wrench (T-B). Remove Thumbscrew (D1) from the back of VESA Bracket (D). Separate VESA Plate (D2) from VESA Bracket. Set Thumbscrew aside.
- Page 10 STEP 4 Secure VESA Plate (D2) to your monitor using appropriate Screws (M-A,M-B), Washers (M-C), and Phillips screwdriver. M-A, M-A, Arrow Arrow Arrow Arrow During installation of VESA Plate (D2), the Arrow should be facing towards the top of your monitor.
- Page 11 Adjusting the Tilt Joint Adjustment Screw Loosen Tilt Joint: Lock Angle Use 6mm Allen Wrench (T-B) to Tighten as much as possible loosen the tilt joint Adjustment using the 6mm Allen Wrench Screw, located on the side of (T-B) to lock the angle. VESA Bracket (D).
- Page 12 With the assistance of a second person, line up the VESA Plate (D2) on your monitor with the VESA Bracket and the Plate Hooks into the pockets of the VESA Bracket (D). 2 Person Mounting is Recommended *Monitor & VESA Bracket may need to be angled backwards slightly when sliding on.
- Page 13 Fine Tune Tilt Angle If the monitor is angled further than intended... Heavy Weighted/ Ultrawide Monitors [ 22lbs - 44lbs ] Firmly Hold Monitor Firmly grasp and hold the monitor in place. Do NOT release monitor until you have completed steps below. Loosen Tilt Joint: With a hand still on the monitor, use 6mm Allen Wrench (T-B) to loosen the tilt joint...
- Page 14 STEP 5 Adjusting Monitor Height Position Mount Arm Turn 10-20x to Set Monitor Height Position the arm horizontally, as shown above, and firmly hold in Turn 6mm Allen Wrench (T-B) 10-20 times place. to obtain proper support for your monitor. Use the guide below to adjust the tension according to the amount of counterbalance Insert...
- Page 15 STEP 6 Route cable using built-in cable cover. Remove bottom cover by sliding forward. Remove top cover as shown.
- Page 16 LAST UPDATED: 7/16/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
