1.6.5

Disk LEDs and Labels

FIGURE 1-2
bottom rim of the chassis in front of the row of disk slots. The SCSI ID that applies
to a disk is shown in a rectangle in front of its disk slot.
Disk SCSI IDs
FIGURE 1-2
1.6.5.1

Disk LEDs

A two-color LED is located above each disk slot. These disk LEDs are visible when
the front door is closed.
TABLE 1-4
LED State
Unlit
Green
1-8 Sun StorEdge D2 Array Installation, Operation, and Service Manual • February 2002
shows the location of the disk LEDs. A label is positioned across the
.
Array Front With Disk LEDs and SCSI IDs
TABLE 1-4
Disk LEDs' Descriptions
Description
No disk drive is in the slot.
A disk drive is present but not active.
Disk LEDs
describes the possible states of the disk LEDs.
