GHARiENi MLL Instruction Manual

Electric spa table
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Phone:
E-Mail:
Service Hotline: +49 (0)2841/88300-40
Instruction manual
Electric Spa Table
MLL / MLK
Gharieni Group GmbH
Gutenbergstraße 40
D – 47443 Moers
+49 (0)2841/88300-0
service@gharieni.de
Fax:
+49 (0)2841/88300-999
Web: www.gharieni.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MLL and is the answer not in the manual?

Questions and answers

Related Manuals for GHARiENi MLL

Summary of Contents for GHARiENi MLL

  • Page 1 Instruction manual Electric Spa Table MLL / MLK Gharieni Group GmbH Gutenbergstraße 40 D – 47443 Moers Phone: +49 (0)2841/88300-0 Fax: +49 (0)2841/88300-999 E-Mail: service@gharieni.de Web: www.gharieni.de Service Hotline: +49 (0)2841/88300-40...

  • Page 2: Table Of Contents

    Index 1. Safety information ...................... 3 2. General information ....................4 3. Before initial use/space requirement ............... 5 4. Intended use ........................ 5 5. Unpacking ........................6 6. Height .......................... 6 7. Head rest ........................6 8. Manual control panel ....................6 9.

  • Page 3: Safety Information

    The connection must be carried out in accordance with the current local and legal regulations. 2. Do not connect the MLL/MLK to the mains if the MLL/MLK itself or the power cable or the plug are visibly damaged. 3. Never try to repair the MLL/MLK yourself. If the MLL/MLK does not operate properly, please contact the manufacturer or the shop you purchased the appliance at.

  • Page 4: General Information

    .Our MLL/MLK is very robust and has a long operating life if it is operated properly. Read the instructions very carefully and operate the appliance in its intended use as described only to protect you and your customers from danger..

  • Page 5: Before Initial Use/Space Requirement

    Read the instructions very carefully and only operate the device in its intended use as described to protect you and your customers from danger. The MLL/MLK is a Spa Table which is suitable for many different kinds of massages. The max. lifting capacity is 160 kg.

  • Page 6: Unpacking

     Open the top of the packaging carefully. Do not use any sharp-edged items which can damage the upholstery.  Do not lift the MLL/MLK but remove the top packaging first. Then you can lift and remove the outer packaging NOTICE! If the floor is not level, you must ensure proper stability using the adjusting screw.

  • Page 7: Optional Equipment

    9. Optional equipment 9.1 Foot switch The MLL/MLK is optional available including a foot switch for 2 electric motors. The advantage of this option is that you have both hands free during treatment. 9.2 Smart-Thermo heater WARNING 1. Do not use the option Smart-Thermo when your customer ...
  • Page 8 Operation You can operate the heater using the 4 buttons ON/OFF/+/-.The setting of the heating power is indicated by a 10-level LED bar-diagram. The green LEDs 1-4 indicate low power/low temperatures. The yellow LEDs 5-7 indicate medium power/medium temperatures. The red LEDs 8-10 indicate high power/high temperatures. Heating Switch on the heater using the ON-button on the HCP.
  • Page 9 1. Press and hold the OFF-button. 2. Press and release the ON-button. 3. Release the OFF-button and enter the Setting of the total operation period You can set 10 levels from 10 to 100 minutes. The position of the single and illuminated LED - from the left to the right - indicates the level.

  • Page 10: Technical Data

    10. Technical data Total length approx. 195 cm Width approx. 70 cm Height/lying surface 62-92 cm Inclination headrest MLL: 0 to 74 MLK: +/- 30 Weight approx. 77 kg Lying surface lifting capacity 160 kg (max. safe operational load Power of transformer (primary) 230V AC/50Hz/70 VA max.

  • Page 11: Cleaning And Maintenance

    1. Repairs and modifications must be carried out by Gharieni Group GmbH or a person authorized by Gharieni Group GmbH. 2. The electrical installation of the room the MLL/MLK is installed in must meet the current legal regulations at the site where the MLL/MLK is operated.

  • Page 12: Waste Management

    Upon delivery, it is necessary to check that the equipment has not been damaged during transportation and that the set of accessories is complete and in good condition. Claims must be filed within 8 days after the delivery of the Gharieni MLL/MLK. Apart from the cases specified in the supply agreement, the guarantee is void when: ...

  • Page 13: Ec-Declaration Of Conformity

    14. EC-Declaration Of Conformity EC DECLARATION OF CONFORMITY Gharieni Group GmbH (Manufacturer) Gutenbergstraße 40; D-47443 Moers; Germany declare that the product MLL/MLK (Type or model; name) is produced in accordance with the requirements specified in Low Voltage Directive (LVD) 2006/95/EG...
  • Page 14 THE PROPERTY RIGHTS OF THIS INSTRUCTION MANUAL ARE RESERVED. ITS REPRODUCTION OR TRANSMISSION TO THIRD PARTIES IS FORBIDDEN WITHOUT THE AUTHORISATION OF THE OWNING COMPANY. THE POWER TO PROTECT ITS RIGHTS IS RESERVED AND OFFENDERS SHALL BE PROSECUTED. Gharieni Group GmbH Gutenbergstraße 40 D – 47443 Moers...

This manual is also suitable for:

Mlk
