This manual contains important safety information
concerning the maintenance, use and operation of this
product. Failure to follow the instructions contained in this
manual may result in serious injury. If you're unable to
understand the contents of this manual, please bring it to
the attention of your supervisor. Do not operate this
equipment unless you have read and understood the
contents of this manual.
Quick Thaw
HQT Series
Installation &
Operating Manual
I&W #07.05.168.00
2 3 :5 9
1 2 :5 9
CL OC
K
REC ALL
CLE AR
H
M
59
59
T 1
T 2
S
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso y
operación de este producto. Cualquier falla en el
seguimiento de las instrucciones contenidas en este
manual puede resultar en un serio daño. Si usted no
puede entender el contenido de este manual por
favor pregunte a su supervisor. No opere este
equipo al menos que haya leído y comprendido el
contenido de este manual.
Advertisement
Table of Contents
Related Manuals for Hatco HQT-1
Summary of Contents for Hatco HQT-1
- Page 1 Operating Manual This manual contains important safety information concerning the maintenance, use and operation of this product. Failure to follow the instructions contained in this manual may result in serious injury. If you’re unable to understand the contents of this manual, please bring it to the attention of your supervisor.
-
Page 2: Table Of Contents
IMPORTANT OWNER INFORMATION Record model number, (identification decal located on the bottom of the shelf), and purchase date of your Hatco Quick Thaw unit in the spaces below. Please have this information available when contacting Hatco for service assistance. Model No. ________________________________ Serial No. -
Page 3: Important Safety Information
WARNINGS For safe and proper operation, the unit must be located at a reasonable working height. To avoid injury or damage to the unit Hatco mounting gussets must be used when mounting unit to the wall. Mounting gussets have a maximum weight capacity of 50 lbs. -
Page 4: Specifications
(recommended) for rapidly thawing frozen food in the HQT-1. Accessories for the HQT-1 are a 12" x 20" x 6" (305 x 508 x 152 mm) perforated food pan and a wire support rack for thawing individual cryopacked serving packages (up to two racks per pan). -
Page 5: Installation
UNPACKING Hatco Quick Thaw units are shipped from the factory partially assembled. (See Figure 3.) 1. Remove HQT-1 unit parts from box. 2. Remove information packet. To prevent delay in obtaining warranty coverage, fill out and mail in the warranty card. -
Page 6: Cavity Housing Assembly
INSTALLATION CAVITY HOUSING ASSEMBLY NOTE: Left side panel has no hole for the water manifold connections. The side panels are not interchangeable and will not fit into the shelf/drain unit if assembled otherwise. 1. Position core panel upright onto the right side edge. -
Page 7: Shelf Installation
SHELF INSTALLATION CAUTION Do not place anything on top of the unit; doing so could damage the unit or subject personnel to possible injury. CAUTION Use of excessive force when tightening mounting screws may damage unit or wall. NOTE: When mounting the shelf to the wall, secure the gussets directly to the wall studs or use toggle bolts (not supplied) if unable to secure unit directly to wall studs. -
Page 8: Water Manifold Assembly
A qualified plumber is recommended for providing 1/2" hot and cold supply water lines with shut off valves to the designated HQT-1 location. NOTE: Installation instructions are provided with mixing valve. Mixing valve is factory calibrated to the low setpoint and will need to be adjusted after installation. -
Page 9: Operation
TEMPERATURE CONTROL Recommended thawing temperature is not to exceed 69°F (21°C). For ideal operating conditions, the cold water supply should be at least 10°F (5.5°C) cooler than the desired setpoint, and the hot water supply should be at least 10°F (5.5°C) above the desired setpoint. 180°F (82°C) is the maximum temperature for the hot water supply inlet on the mixing valve. -
Page 10: Thawing Procedure
THAWING PROCEDURE CAUTION For safe and proper operation do not place food product directly onto bottom of Hatco Quick Thaw unit. Use of a perforated pan is recommended for holding food product. There are many variables that effect the amount of time it takes to safely thaw frozen food product. -
Page 11: Timer Device
TIMER DEVICE (OPTIONAL) Set Clock 1. Slide switch (located on the back of the unit) to “CLOCK SET.” 2. Press “CLOCK” to select 12 or 24 hour display. 3. Press “H” to set hours. Press “M” to set minutes. Press “S” to reset seconds to zero. 4. -
Page 12: Maintenance
The cavity housing has been designed to allow for easy disassembling, cleaning, and sanitizing. It is recommended to clean and sanitize the HQT-1 at the end of each days use. 1. Turn off water supply at the hot and cold shut off valves. -
Page 13: Accessories
ACCESSORIES PERFORATED FOOD PAN The perforated food pan allows for large frozen food product to be safely handled within the HQT-1. The perforated food measurements 12" x 20" x 6" (305 x 508 x 152 mm) WIRE SUPPORT RACK The wire support rack allows the thawing of several individually cryopacked serving packages at one time. -
Page 14: Hatco Limited Warranty
Hatco reserves the right to accept or reject any such claim in whole or in part. Hatco will not accept the return of any Product without prior written approval from Hatco, and all such approved returns shall be made at Buyer’s sole expense. - Page 15 NOTES Form No. HQTM-0206...
-
Page 16: Authorized Parts Distributors
Cone’s Repair Service Flanders Moline 309-797-5323 P.O. Box 340500, Milwaukee, WI 53234-0500 U.S.A. Parts & Service Fax (800) 690-2966 Printed in U.S.A. February 2006 HATCO AUTHORIZED PARTS DISTRIBUTORS NEW YORK Acme American Repairs, Inc. 317-545-9655 Brooklyn Alpro Service Co. Brooklyn...
