U-Line SHARK ROTATOR LIFT-AWAY H-10108 Manual

H-10108
SHARK ROTATOR
LIFT-AWAY VACUUM
®
OPERATING ISSUE
Vacuum is not picking
up dirt. No suction or
light suction.
Vacuum lifts area rugs.
Brush roll does not spin.
PAGE 1 OF 6
1-800-295-5510
uline.com
®
TROUBLESHOOTING
CAUSES
Dust cup may be full.
Filters may need cleaning.
Hose may be blocked.
The suction release on the
handle may be open.
Suction is too powerful for type
of rug: area rug or rug with
delicately sewn edges.
Brush roll needs to be
disengaged.
The auto-off feature may be
engaged.
There may be a blockage in
the bottom of floor nozzle or
brush roll.
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
RECOMMENDATIONS
Empty dust cup.
Check filters to see if they need cleaning.
Follow instructions for rinsing and drying
the filters before re-inserting back into the
vacuum.
Check hose, hose connections, nozzles
and accessories for blockages; clear
blockages if required.
Close the suction release on the handle
to increase suction power.
Open the suction release on the handle
to decrease suction power.
Turn off the unit to disengage the brush
roll and restart with the POWER button for
suction-only cleaning.
Pull handle toward you and release floor
nozzle to disengage the auto-off feature.
Turn unit on by pressing the BRUSH ROLL
button.
Immediately turn off and unplug vacuum,
disconnect the nozzle and remove
blockage before reconnecting and
turning vacuum back on.
0722 TH-8041
