H-10132
SHARK
WANDVAC
®
VACUUM
WARNING! To reduce the risk of injury, fire,
electric shock and property damage resulting
from improper use of the appliance, carefully
observe the following instructions. This unit
contains electrical connections and moving
parts that potentially present risk to the user.
ELECTRICAL CONNECTIONS
• There are no serviceable parts.
• Do not use to vacuum any liquids.
• Do not immerse in water or other liquids.
• If vacuum is damaged, discontinue use.
• To avoid fire, explosion or injury, inspect vacuum
and charging dock for any damage before use.
• Do not use damaged vacuum or charging dock.
• Do not use outdoors or on wet surfaces.
• Do not handle charger or vacuum cleaner with
wet hands.
• Do not leave vacuum cleaner unattended while
powered on.
• Keep vacuum away from heated surfaces.
• Always turn off vacuum before connecting
charging dock.
• Only use Shark
chargers and batteries.
®
Other types of batteries may burst, causing injury
and damage.
• Use charging dock on flat and stable surfaces only.
• Do not incinerate appliance, even if it is severely
damaged, as lithium-ion battery may explode in
a fire.
PAGE 1 OF 15
1-800-295-5510
uline.com
SAFETY
• If vacuum cleaner is not working as it should or
has been dropped, damaged, left outdoors or
immersed in water, call Uline Customer Service
at 1-800-295-5510.
GENERAL USE
• Do not carry the charger by the cord or yank to
disconnect from an outlet; instead, grasp the plug
and pull to disconnect.
• Keep charger cord away from heated surfaces.
• Use only as described in these instructions.
• Keep work area well-lit.
• To avoid unintentional starting, always turn off the
vacuum cleaner before picking it up or carrying
it and before attaching or detaching the charger,
dust cup, filter or any accessories.
• Do not put any objects into openings.
• Do not use if any opening is blocked; keep free of
dust, lint, hair or anything that may reduce airflow.
• Do not allow young children to operate the
appliance or use as a toy. Close supervision is
necessary when any appliance is used near
children.
• Do not use without dust cup and filter in place.
• Do not use if airflow is restricted. If the air paths
become blocked, turn off the vacuum cleaner.
Clear all obstructions and power on again.
• Keep nozzle away from hair, face, fingers,
uncovered feet or loose clothing.
• Only use manufacturer's recommended
attachments.
Para Español, vea páginas 6-10.
Pour le français, consulter les pages 11-15.
0622 IH-10132

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SHARK H-10132 and is the answer not in the manual?

Questions and answers

Summary of Contents for U-Line SHARK H-10132

  • Page 1 Para Español, vea páginas 6-10. Pour le français, consulter les pages 11-15. H-10132 1-800-295-5510 uline.com SHARK WANDVAC ® VACUUM SAFETY WARNING! To reduce the risk of injury, fire, • If vacuum cleaner is not working as it should or electric shock and property damage resulting has been dropped, damaged, left outdoors or from improper use of the appliance, carefully immersed in water, call Uline Customer Service...
  • Page 2: General Cleaning

    SAFETY CONTINUED LITHIUM-ION BATTERY • Do not charge at temperatures below 50°F or above 104°F. Charging improperly or at • The battery is the power source for the appliance. temperatures outside of the specified range may Do not carry the appliance with your finger on the damage the battery and increase the risk of fire.
  • Page 3: Charging Battery

    PARTS Shark ION Power ION Charging Multi-Surface Duster Crevice Onboard Accessory ® Handheld x 1 Dock x 1 Pet Tool x 1 Tool x 1 Storage x 1 CHARGING BATTERY IMPORTANT! Prior to first use, the lithium-ion 2. Plug charging dock into wall outlet. battery must be charged completely, even if it NOTE: During first use, discharge fully to comes with a partial charge.
  • Page 4: Maintenance

    MAINTENANCE EMPTYING DUST CUP 3. While pressing dust cup tab, lift off dust cup. Hand-wash with soap and water only. Let parts With power off and dust cup facing downward over air-dry fully before reinstalling. (See Figure 9) trash receptical, slide the dust cup button forward. 4.
  • Page 5: Troubleshooting

    TROUBLESHOOTING LIGHT INDICATOR MEANING Light blinking blue. Low battery. Light blinks blue twice, then pauses. Blockage. Turn off power and remove blockage, then turn power back on. Solid blue light. Power is on. Dim blue light. Unit is charged. No light. Power is off, or unit needs recharge.
  • Page 6: Conexiones Eléctricas

    H-10132 800-295-5510 uline.mx SHARK WANDVAC ® ASPIRADORA SEGURIDAD ¡ADVERTENCIA! Para reducir el riesgo de • Utilice la base de carga solo sobre superficies lesiones, incendios, descarga eléctrica planas y estables. y daños a la propiedad que resulten del • No incinere el aparato, incluso si está gravemente uso inadecuado del aparato, observe con dañado, ya que la batería de iones de litio podría cuidado las instrucciones a continuación.
  • Page 7: Limpieza General

    CONTINUACIÓN DE SEGURIDAD • No utilice si el flujo de aire está restringido. Si • No aspire materiales inflamables o combustibles se obstruye la circulación del aire, apague la (fluidos ligeros, gasolina, o queroseno) o use aspiradora. Despeje todas las obstrucciones y la aspiradora en áreas donde pudieran estar vuelva a encenderla.
  • Page 8: Cargar La Batería

    PARTES 1 Shark® ION 1 Base de Carga 1 Herramienta 1 Herramienta 1 Almacenamiento Power Portátil Multisuperficie Quita Polvo para a Bordo para para Mascotas Hendiduras Accesorios CARGAR LA BATERÍA ¡IMPORTANTE! Antes del primer uso, la batería Conecte la base de carga a un enchufe. de iones de litio debe primero cargarse por NOTA: Durante el primer uso, descárguela completo, incluso si viene con una carga...
  • Page 9: Mantenimiento

    MANTENIMIENTO VACIAR EL RECIPIENTE PARA POLVO 3. Mientras presione la pestaña del recipiente para polvo, levante el recipiente para polvo. 1. Con la aspiradora apagada y el recipiente para Lave a mano con detergente y agua solamente. polvo hacia abajo sobre el receptáculo de basura, Permita que las partes se sequen al aire por deslice el botón del recipiente para polvo hacia completo antes de volver a instalarlas.
  • Page 10: Solución De Problemas

    SOLUCIÓN DE PROBLEMAS LUZ INDICADORA SIGNIFICADO Azul claro parpadeante. Batería baja. La luz parpadea azul dos veces, luego se Obstrucción. Apague y retire la obstrucción, luego detiene. vuelva a encender. Luz azul sólida. Está encendida. Luz azul tenue. La unidad está cargada. No hay luz.
  • Page 11: Connexions Électriques

    π H-10132 1-800-295-5510 uline.ca SHARK WANDVAC – ASPIRATEUR SÉCURITÉ AVERTISSEMENT! Observez scrupuleusement • Utilisez la station de recharge uniquement sur des les instructions suivantes afin de réduire les surfaces planes et stables. risques de blessures, de chocs électriques • Il ne faut en aucun cas incinérer l'appareil même et de dommages matériels provenant d'une lorsqu'il est fortement endommagé, car la batterie utilisation impropre de l'appareil.
  • Page 12: Nettoyage Général

    SÉCURITÉ SUITE à poussière et un filtre. • N'aspirez aucun matériau inflammable ou combustible (essence à briquet, essence • Ne l'utilisez pas si la circulation de l'air est entravée. automobile, kérosène) et n'utilisez pas l'aspirateur Si les passages d'air sont bloqués, éteignez-le. dans les endroits où...
  • Page 13: Recharge De La Batterie

    PIÈCES Aspirateur à main Station de Accessoire Suceur plat Porte-accessoire électrique Shark recharge ION x 1 multisurface et brosse à intégré x 1 ION x 1 pour animaux x 1 épousseter x 1 RECHARGE DE LA BATTERIE IMPORTANT! Avant la première utilisation, la 2.
  • Page 14: Entretien

    ENTRETIEN VIDANGE DU BAC À POUSSIÈRE 3. Pendant que vous appuyez sur la languette, soulevez le bac à poussière. Lavez-le à la main Lorsque l'appareil est éteint, tournez le bac à avec du savon et de l'eau uniquement. Laissez poussière vers le bas au-dessus d'une poubelle et les pièces sécher complètement à...
  • Page 15: Dépannage

    ENTRETIEN SUITE NETTOYAGE DU FILTRE REMARQUE : Pour nettoyer le filtre en tissu, tapotez-le pour enlever la poussière et les 1. Tout en maintenant le bac à poussière ouvert particules plus larges. Pour un nettoyage en et l'appareil éteint, pressez les deux côtés du profondeur, lavez-le à...
