π
H-7147
SANITAIRE
EON
®
QUIET CLEAN
NOTE: When using an electrical appliance,
basic precautions should always be followed,
including the following: READ ALL INSTRUCTIONS
BEFORE USING THIS VACUUM.
WARNING! To reduce the risk of fire, electric
shock or injury:
• Do not use outdoors or on wet surfaces.
• Connect to a properly grounded outlet only. See
Grounding on page 2.
• Do not leave vacuum cleaner when plugged in.
Turn off and unplug when not in use and before
servicing.
• Always turn off vacuum before connecting or
disconnecting motorized nozzle.
• Do not use as a toy. Close attention is necessary
when used by or near children.
• Use only as described in these instructions. Use only
Uline's recommended attachments.
• Do not use with damaged cord or plug. If vacuum
is not working as it should, has been dropped,
damaged, left outdoors or dropped into water, call
Uline Customer Service at 1-800-295-1150.
• Do not pull or carry by cord. Do not use cord as
a handle. Do not close door on cord or pull cord
around sharp edges or corners. Do not run vacuum
over cord. Keep cord away from heated surfaces.
• Do not use extension cord or outlet with
inadequate current-carrying capacity.
• Turn off all controls before unplugging.
• Do not unplug by pulling on cord. To unplug, grasp
the plug, not the cord.
PAGE 1 OF 9
VACUUM
®
1-800-295-5510
uline.com
SAFETY
• Do not handle plug or vacuum with wet hands.
• Do not put foreign objects into openings. Do not
use with any opening blocked. Keep free of dust,
lint, hair and any material that reduces airflow.
• Vacuum creates suction and contains a revolving
brush roll. Keep hair, loose clothing, fingers and
all parts of body away from openings and moving
parts.
• Do not place vacuum on furniture or stairs, as the
brush roll may cause damage.
• Use extra care when cleaning stairs.
• Place vacuum cleaner on floor with the handle in
storage position while using attachments.
• Do not use to pick up anything that is burning or
smoking, such as cigarettes, matches or hot ashes.
• Do not use without disposable dust bag and motor
filter in place.
• Belt pulleys can become hot during normal use. To
prevent burns, avoid touching the belt pulley when
servicing the drive belt.
• Do not use to pick up flammable or combustible
liquids, such as gasoline, or use in areas where
they may be present.
• Store vacuum indoors in a cool, dry area.
• Keep work area well lit.
• Unplug electrical appliances before vacuuming.
WARNING! Vacuum contains chemicals known
to the state of California to cause cancer, birth
defects or reproductive harm. Wash hands
after handling.
0118 IH-7147

Advertisement

Table of Contents
loading

Summary of Contents for U-Line SANITAIRE EON QUIET CLEAN H-7147

  • Page 1 π H-7147 1-800-295-5510 uline.com SANITAIRE ® ™ QUIET CLEAN VACUUM ® SAFETY NOTE: When using an electrical appliance, • Do not handle plug or vacuum with wet hands. basic precautions should always be followed, • Do not put foreign objects into openings. Do not including the following: READ ALL INSTRUCTIONS use with any opening blocked.
  • Page 2: Thermal Cutoff

    SETUP THERMAL CUTOFF Grounded Figure 1 Vacuum cleaner has a thermostat that protects itself in Outlet case of motor overheating. Grounded Outlet Box If vacuum shuts off, turn off power switch, unplug and complete the following: 1. Check for source of overheating, such as full dust bag, blocked hose or clogged filter.
  • Page 3 ASSEMBLY Upper Cord Retainer Cord Clip Handle Assembly Wand with Handle Grip and Hose Inlet Clip Handle Lock Hose Inlet Carrying Handle Lower Cord Retainer Crevice Tool Quick Change Power Cord Upholstery Tool Handle Release Remove and identify all parts from carton. Make 4.
  • Page 4: Operation

    ASSEMBLY CONTINUED 6. Insert wand with handle grip and hose into channel 8. Push remaining hose end into hose inlet. Inlet clip at the back of vacuum. Place handle grip over tab will lock hose into place when fully inserted. to latch into position.
  • Page 5: Cleaning Tools

    OPERATION CONTINUED VACUUM CLEANER HEIGHT SETTING 2. To use the hose without the wand, pull wand handle from docked position. Push lever and pull hose out WARNING! Avoid injury. Keep loose clothing, of wand. Attach desired tool. (See Figure 11) hair, fingers and all other body parts away from any moving part (such as the revolving Figure 11...
  • Page 6 OPERATION CONTINUED CLEANING AIR PATH BRUSHROLL CHECK LIGHT 1. To check nozzle head, remove cover from air path 3. If red light stays off, brushroll is operating correctly. cleanout. Turn cover counterclockwise and pull off. 4. If red light turns on or brushroll stalls, vacuum will turn 2.
  • Page 7: Maintenance

    MAINTENANCE CAUTION! Turn off power switch and unplug CLEANING/REPLACING PRE-MOTOR FILTER electrical cord before maintenance. Pre-motor filter is located under dust bag. Check filter CHANGING DUST BAG each time dust bag is changed. (See Figure 18) Lift up cover latch release and pull off cover. Figure 18 (See Figure 16) 2.
  • Page 8: Replacing Brushroll

    MAINTENANCE CONTINUED REPLACING BRUSHROLL 3. Rotate brushroll forward (clockwise) and lift out. Remove debris. (See Figure 22) CAUTION! Ensure vacuum is turned off and unplugged before replacing the brushroll. Figure 22 Routine maintenance of your vacuum will help avoid unnecessary service calls. Check the brushroll often. Lay vacuum on side so brushroll side plate is on top.
  • Page 9: Troubleshooting

    TROUBLESHOOTING OPERATING ISSUE CAUSES RECOMMENDATIONS Motor will not start. Power switch. Turn power switch on and wait one minute. Push plug securely into extension Power plug. cord. Press cord into clip to secure the connection. Plug extension cord securely into outlet. Try another outlet.
