- Page 1 Operation manual COACH PRO Personal Wireless PA System CHIAYO ELECTRONICS CO., LTD.
- Page 2 ◼ Use only manufacturer authorized or recommended accessories. ◼ Use only with a cart, stand, tripod or accessories specified or provided by Chiayo. Be careful when using a cart to avoid injury from tip-over. ◼ Unplug the product during an electrical strom or when unused for long periods of time.
-
Page 3: Table Of Contents
Operation manual INDEX 1. Instruction ..........................4 1-1. In the box ..........................4 1-2. Optional related products ....................4 1-3. Parts and functions ......................5 1-4. Charging the battery ......................5 1-5. Connection with external audio sources ................6 2. Settings and Operations ......................7 2-1. Using the wired microphone (MIC IN)................7 2-2. - Page 4 Instruction Warning Please read and follow the instructions in this manual thoroughly to obtain optimum results from this unit. We also recommend that you keep this manual handy for future reference. Safety Precautions ◼ Be sure to read the instructions in this section carefully before use. ◼...
-
Page 5: Instruction
1. Control unit compartment on the rear panel 2. Battery compartment on the bottom Battery compartment Control unit compartment 1-1. In the box COACH PRO amplifier 0-1 handheld / beltpack transmitter Switching power supply (optional) (plug varies from country to country) operation manual 1-2. Optional related products ▍Transmitters... -
Page 6: Parts And Functions
Instruction 1-3. Parts and functions Battery compartment MP3 recorder player Wireless receiver volume Wireless receiver channel Wireless receiver AUX / MP3 player & recorder control (optional) selector (optional) ON/OFF indicator volume control (optional) ECHO control TONE control Master power / MIC Master volume control volume control Emergency alarm (2... -
Page 7: Connection With External Audio Sources
COACH PRO Personal Wireless PA System 1-5. Connection with external audio sources USB disk AMPLIFIER TABLET / PHONE WIRED MIC Sound control, e.g., volume and equalizer, of audio output from COACH PRO is only operated on this external amplifier. -
Page 8: Settings And Operations
Settings and Operations 2. Settings and Operations 2-1. Using the wired microphone (MIC IN) Plug a wired microphone with a 6.3mm plug to MIC IN. Turn ON master POWER and adjust MASTER volume to default level (12 o’clock). Then adjust PWR/MIC volume control to desired level. LOW-HIGH TONE and ECHO can be adjusted. -
Page 9: Using The Wireless Receiver
COACH PRO Personal Wireless PA System 2-2. Using the wireless receiver Turn ON master POWER and WR VOL in order, the receiver’s power indicator will glow RED. After turning ON the transmitter, this LED will turn GREEN. Power ON RED Signal received ... -
Page 10: Music Audio Input (Aux In)- Smart Phone / Tablet / Mp3 Player
Settings and Operations 2-3. Music audio input (AUX IN)- Smart phone / tablet / MP3 player Connect your device to the 3.5mm jack of AUX IN with a 3.5mm 3-pole stereo audio cable. Turn ON master POWER and adjust MASTER volume to default level (12 o’clock). Then adjust AUX/USB volume control to a desired level. -
Page 11: Using The Mp3 Player & Recorder
COACH PRO Personal Wireless PA System 2-4. Using the MP3 player & recorder 2-4-1. Parts and functions Previous / fast play/pause Next / fast forward USB input LCD display reverse button button button Remote control Stop button IR sensor area... - Page 12 Settings and Operations Turn ON master POWER and AUX/USB in order. Plug the USB and the music will play automatically. To dispatch the USB, please turn off the player first. Turn ON master POWER and adjust MASTER volume to default level (12 o’clock). Then adjust AUX/USB volume control to desired level.
-
Page 13: Tone For Wired And Wireless Microphone And Music
COACH PRO Personal Wireless PA System 2-5. TONE for WIRED and WIRELESS MICROPHONE and MUSIC TONE adjustment is actually used to increase or reduce the high/low frequency component of the speaker's restored sound. It is so-called raising or attenuating HIGH (MAX) / BASS (MIN) via frequency-specific volume knob to improve human voices or make musical instruments’... -
Page 14: Faq & Useful Operation Tips
(microphone, MP3 ... etc.). Is it possible to play music storing on external devices via wireless amplifier? Yes. COACH PRO wireless amplifier has an auxiliary audio input (AUX IN) for connection with external devices such as notebook, mobile phones or tablets. The built-in MP3 recorder has remote control and offers more versatile functionality. - Page 15 The battery life is limited and affected by the environment, charging method and battery efficiency. Is it possible that COACH PRO can work as amplifier only? Can I use only one or more microphones? How many wireless microphones can be used at most? COACH PRO can work as amplifier only.
-
Page 16: Maintenance-Free Lead-Acid And Lithium Batteries
2. Please use the power supply specified by CHIAYO for charging. 3. The CHIAYO amplifier has a protection circuit to prevent overcharging. To ensure safety, the charging time should not exceed 12 hours. Please disconnect the power supply when fully charged.
