ON Semiconductor ASX370CS User Manual

ASX370CSSC27SUFAH-GEVB
ASX370CS
Evaluation Board
User's Manual

Evaluation Board Overview

The evaluation boards are designed to demonstrate the features of
image sensors products from ON Semiconductor. This headboard is
intended to plug directly into the Demo 2X system. Test points and
jumpers on the board provide access to the clock, I/Os, and other
miscellaneous signals.

Features

•
Clock Input
Default – 27 MHz Crystal Oscillator
♦
Optional Demo 2X Controlled MClk
♦
•
Two-wire Serial Interface
Selectable Base Address
♦
•
Parallel Interface
•
MIPI Interface
•
ROHS Compliant

Block Diagram

© Semiconductor Components Industries, LLC, 2016
April, 2016 − Rev. 0
Figure 2. Block Diagram of ASX370CSSC27SUFAH−GEVB
EVAL BOARD USER'S MANUAL
Figure 1. ASX370CS Evaluation Board
1
www.onsemi.com
Publication Order Number:
EVBUM2408/D
