Page 1: Table Of Contents
50-000-611 DOC TRANSIT GB FDI C INSTALLATION GUIDE CONTENT INTRODUCTION: CERTIFICATION AND WARRANTY..................SYSTEM OVERVIEW......................TECHNICAL FEATURES....................... OPERATING PRINCIPLES....................IN WHICH CONFIGURATION DO YOU USE TRANSIT ? ............CONFIGURATION N°1....................... CONFIGURATION N°2....................... CONFIGURATION N°3....................... CONFIGURATION N°4....................... CONTROLLER PARAMETERS PROGRAMMATION............... WIRING FOR DOOR CONTROL.................... -
Page 2: Certification And Warranty
50-000-611 DOC TRANSIT GB FDI B DECLARATION OF CONFORMITY Declaration of conformity: FDI Matelec certifies that Transit complies with the requirements of the European Community Directive: R&TTE 99/5/CE. Assessment of the product’s compliance with requirements based on the following standards: Regarding short range devices: ETS300683 (1997) Regarding radio emission: ETS300330-2 (1994) Regarding the safety of IT equipment: EN60950 (2000) -
Page 3: System Overview
50-000-611 DOC TRANSIT GB FDI C SYSTEM OVERVIEW Transit is a dual technology door opener system. It controls the opening of one or two electrical locks with proximity keys or dual technology keys. Up to 500 proximity or dual technology keys for Transit 500 and up to 999 proximity or dual technology keys for Transit 999 can be programmed to open one or two locks. - Page 4 50-000-611 DOC TRANSIT GB FDI C TECHNICAL FEATURE General information The unit presents a three digit, three dot display with three programming buttons, a backup memory, a connection terminal board, a built-in reader for key programming and an instrument for measuring RF perturbation 1.
-
Page 5: Technical Features
50-000-611 DOC TRANSIT GB FDI C TECHNICAL FEATURES Wiring RF Antenna 433MHz in option 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 C NC NO C NC NO L+ L- LD L+ L- LD Relay Relay... -
Page 6: Operating Principles
50-000-611 DOC TRANSIT GB FDI C OPERATING PRINCIPLES 1. Operation You have a bi-technologie unit capable of controlling two accesses. For example: a car-park gate and a building access door. To control the doors, you can use the combined proximity and RF keys or the proximity keys. The remote control receiver is integrated in the unit. -
Page 7: In Which Configuration Do You Use Transit
50-000-611 DOC TRANSIT GB FDI C IN WHICH CONFIGURATION DO YOU USE TRANSIT? Door 1 controlled by channel 1 Door 2 controlled by channel 2 GO TO PAGE N° 8 Door 1 controlled by channel Door 2 controlled by the proximity key or the proximity key integrated in the remote control... -
Page 8: Configuration N°1
50-000-611 DOC TRANSIT GB FDI C DOOR 1: controlled by channel 1 DOOR 2: controlled by channel 2 Door 1 controlled by channel 1 Door 2 controlled by channel 2 RF Antenna 433MHz in option 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Power supply... - Page 9 50-000-611 DOC TRANSIT GB FDI C DOOR 1: controlled by channel 1 DOOR 2: controlled by channel 2 1. Entering programming Mode To program the unit, you must first enter in PROGRAMMING mode. In programming mode, the remote controls are not read and cannot control the doors. The pushbutton operates except during use of functions F4 and F5. If the unit does not have a password : Press one of the three programming buttons .The unit displays 00...
-
Page 10: Configuration N°2
50-000-611 DOC TRANSIT GB FDI C DOOR 1: controlled by channel 1 DOOR 2: controlled by the proximity Door 1 controlled by channel Door 2 controlled by the proximity key or the proximity key integrated in the remote control RF Antenna 433MHz 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 in option... - Page 11 50-000-611 DOC TRANSIT GB FDI C DOOR 1: controlled by channel 1 DOOR 2: controlled by the proximity 1. Entering programming Mode To program the unit, you must first enter PROGRAMMING mode. In programming mode the keys and remote controls are not read and cannot control the doors. The pushbutton operates except during use of functions F4 and F5.
- Page 12 50-000-611 DOC TRANSIT GB FDI C DOOR 1: controlled by the proximity DOOR 2: controlled by Channel 2 Door 1 controlled by the proximity key or the proximity key integrated in the remote control Door 2 controlled by channel 2 RF Antenna 433MHz 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20...
- Page 13 50-000-611 DOC TRANSIT GB FDI C DOOR 1: controlled by the proximity DOOR 2: controlled by Channel 2 1. Entering programming Mode To program the unit, you must first enter PROGRAMMING mode. In programming mode the keys and remote controls are not read and cannot control the doors. The pushbutton operates except during use of functions F4 and F5.
- Page 14 50-000-611 DOC TRANSIT GB FDI C DOOR 1: controlled by the proximity DOOR 2: controlled by the proximity Door 1 and Door 2 controlled by the proximity key or the proximity key integrated in the remote control 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Power supply...
- Page 15 50-000-611 DOC TRANSIT GB FDI C DOOR 1: controlled by the proximity DOOR 2: controlled by the proximity 1. Entering programming Mode To program the unit, you must first enter PROGRAMMING mode. In programming mode the keys are not read and cannot control the doors.
-
Page 16: Controller Parameters Programmation
50-000-611 DOC TRANSIT GB FDI C PROGRAMMING THE CONTROLLER PARAMETERS CAUTION: DURING PROGRAMMING, THE KEYS AND REMOTE CONTROLS ARE NOT READ AND CANNOT OPEN THE DOORS. IN ADDITION, WHEN YOU USE FUNCTION F4 OR FUNCTION F5, THE PUSHBUTTON CANNOT CONTROL THE DOOR. 1. - Page 17 50-000-611 DOC TRANSIT GB FDI C PROGRAMMING THE CONTROLLER PARAMETERS 3. Function F3: Relay timeout Enter programming mode. Display function F3 using keys, then validate with the key The display then indicates the number and the lock time release of door 1: for example 103 means that the relay of door 1 is controlled for three seconds.
-
Page 18: Wiring For Door Control
50-000-611 DOC TRANSIT GB FDI C WIRING FOR DOOR CONTROL Controlling a Gate automation (an Open or Closed dry contact is sufficient) Controller If you need an NO (Normally Open) contact Door 1: WORK Terminal n°8: common Gate Terminal n°10: work automated Door 2: system... - Page 19 50-000-611 DOC TRANSIT GB FDI C WIRING FOR DOOR CONTROL Controlling a magnetic fail-safe lock A fail-safe lock (or power to lock) requires a permanent power supply to keep the door locked. For instance in the event of power failure the door would become unlocked. Controller +12V- IDLE...
