B.6.1

Headphone Connector

FIGURE B-7
This connector is used to connect a set of stereophonic headphones to the system for
private listening of audio output.
B.6.2

Audio Line-Out Connector

FIGURE B-8
This connector is used to connect the system audio output to a stereophonic
amplifier and external loudspeakers.
B.6.3

Audio Line-In Connector

FIGURE B-9
This connector is used to connect external stereophonic sound sources such as a
compact disc player or cassette tape player to the system.
B-6 SPARCstation 4/Xterminal 1 Service Manual • January 1995
Headphone Connector
Audio Line-out Connector
Audio Line-in Connector
