4. Route the DC power harness through the metal cable clips.
The two tie-wrap cords on the DC power harness should straddle the cable clip that
is closest to the system board. See
5. Reinstall the CD-ROM SCSI cable (if present).
See section 9.4.2, "Replacing the CD-ROM SCSI Cable."
6. Reinstall the CD-ROM drive (if present).
See section 9.2.2, "Replacing the CD-ROM Drive."
7. Detach the wrist strap and replace the cover.
See Chapter 7.
8. Power on the system.
See Section 6.2 "Powering On the System."
9.6

Diskette Data Cable

9.6.1

Removing the Diskette Data Cable

1. Shut down and power off the system.
See Section 6.1 "Powering Off the System."
2. Remove the cover and attach a wrist strap.
See Chapter 7.
3. Remove the CD-ROM drive (if present).
See Section 9.2.1 "Removing the CD-ROM Drive."
4. Carefully note how the diskette data cable is routed, and disconnect it from the
diskette drive.
5. Remove the diskette drive.
See Section 9.3.1 "Removing the Diskette Drive."
6. Unplug the diskette data cable from the system board and remove it.
See
FIGURE 9-19
FIGURE 9-18
.
.
Chapter 9 Storage Devices 9-19
