Xplained Pro Lcd Connector - Atmel SAM4E Xplained Pro User Manual

Pro Extension Header" on page
Xplained Pro extensions to Xplained Pro MCU boards and to access the pins of the target MCU on Xplained
Pro MCU board directly.
Table 3-4. Xplained Pro Extension Header
Pin number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
3.4.2

Xplained Pro LCD Connector

The LCD connector provides the ability to connect to display extensions that have a parallel interface. The
connector implements signals for a MCU parallel bus interface and a LCD controller interface as well as
signals for a touchcontroller. The connector pin-out definition is shown in
Connector" on page
the MCU bus interface.
A FPC/FFC connector with 50 pins and 0.5mm pitch is used for the LCD connector. The connector
(XF2M-5015-1A) from Omron is used on several designs and can be used as a reference.
Table 3-5. Xplained Pro LCD Connector
Pin number
1
2
3
8. The extension headers can be used to connect a wide variety of
Name
ID
GND
ADC(+)
ADC(-)
GPIO1
GPIO2
PWM(+)
PWM(-)
IRQ/GPIO
SPI_SS_B/GPIO
TWI_SDA
TWI_SCL
USART_RX
USART_TX
SPI_SS_A
SPI_MOSI
SPI_MISO
SPI_SCK
GND
VCC
8. Note that usually only one display interface is implemented, either LCD controller or
Name
ID
GND
D0
Description
Communication line to the ID chip on extension board.
Ground.
Analog to digital converter , alternatively positive part of
differential ADC.
Analog to digital converter , alternatively negative part of
differential ADC.
General purpose I/O.
General purpose I/O.
Pulse width modulation , alternatively positive part of
differential PWM.
Pulse width modulation , alternatively positive part of
differential PWM.
Interrupt request line and/or general purpose I/O.
Slave select for SPI and/or general purpose I/O.
Data line for two-wire interface. Always implemented, bus
type.
Clock line for two-wire interface. Always implemented, bus
type.
Receiver line of Universal Synchronous and Asynchronous
serial Receiver and Transmitter.
Transmitter line of Universal Synchronous and
Asynchronous serial Receiver and Transmitter.
Slave select for SPI. Should be unique if possible.
Master out slave in line of Serial peripheral interface. Always
implemented, bus type.
Master in slave out line of Serial peripheral interface. Always
implemented, bus type.
Clock for Serial peripheral interface. Always implemented,
bus type.
Ground.
Power for extension board.
Table 3-5, "Xplained Pro LCD
RGB interface
description
Communication line to ID chip on extension board.
Atmel SAM4E Xplained Pro [USER GUIDE]
MCU interface
description
Ground
Data line
42216A-MCU-01/2014
