Table 4-17. Virtual COM Port Connections
Pin on SAM4E
PA9
PA10
4.3.3

Atmel Data Gateway Interface

The Embedded Debugger features an Atmel Data Gateway Interface (DGI) by using either a USART or TWI
port. The DGI can be used to send a variety of data from the SAM4E to the host PC. For further information on
how to use the DGI interface see
Table 4-18. DGI Interface Connections When Using USART
Pin on SAM4E
PB0
PB1
PB13
Table 4-19. DGI Interface Connections When Using TWI
Pin on SAM4E
PA3
PA4
Four GPIO lines are connected to the Embedded Debugger. The EDBG can monitor these lines and time
stamp pin value changes. This makes it possible to accurately time stamp events in the SAM4E application
code. For further information on how to configure and use the GPIO monitoring features see
Debugger" on page
Table 4-20. GPIO Lines Connected To the EDBG
Pin on SAM4E
PD27
PE3
PE4
PE2
"Embedded Debugger" on page
6.
Function
URXD0 (SAM4E RX line)
UTXD0 (SAM4E TX line)
6.
Function
RXD0
TXD0
SCK0
Function
SDA (Data line)
SCL (Clock line)
Function
GPIO0
GPIO1
GPIO2
GPIO3
