Table 4-3. Extension Header EXT3
Pin on EXT3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
4.1.2

LCD Extension Connector

Extension connector EXT4 is a special connector for LCD displays. The physical connector is a TE
Connectivity 5-1734839-0 FPC connector.
Table 4-4. LCD Display Connector EXT4
Pin on EXT4
1 [ID]
SAM4E pin Function
PD29 GPIO
PB4 GPIO
PA3 TWD0
PA4 TWCK0
PA5 URXD1
PA6 UTXD1
PD23 GPIO
PA13 MOSI
PA12 MISO
PA14 SPCK
- GND
- VCC
SAM4E pin Function
- Communication
line to ID chip on
extension board.
- GND
PA17 AD0
PC13 AD6
PD28 GPIO
PD17 GPIO
PD20 PWMH0
PD24 PWML0
PE1 GPIO
PD26 GPIO
PA3 TWD0
PA4 TWCK0
PA5 URXD1
PA6 UTXD1
PD30 GPIO
PA13 MOSI
PA12 MISO
PA14 SPCK
- GND
- VCC
SAM4E pin
-
Shared functionality
ETHERNET
EXT1, EXT3, LCD connector and EDBG
EXT1, EXT3, LCD connector and EDBG
EXT3
EXT3
EXT1 and EXT3
EXT1 and EXT3
EXT1 and EXT3
Shared functionality
EXT1, EXT2, LCD connector and EDBG
EXT1, EXT2, LCD connector and EDBG
EXT2
EXT2
EXT1 and EXT2
EXT1 and EXT2
EXT1 and EXT2
Function Shared functionality
Communication
line to ID chip on
extension board.
