dard extension header". The extension headers can be used to connect a wide variety of Xplained Pro exten-
sions to Xplained Pro MCU boards and to access the pins of the target MCU on Xplained Pro MCU board di-
rectly.
Table 3.4. Standard extension header
Pin number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
3.4.2

Xplained Pro segment LCD extension connector

Xplained Pro MCU boards that have a microcontroller that supports segment LCDs contain a 51-pin segment
LCD extension connector. This connector is implemented with HIROSEs DF-9 series. Xplained Pro MCU
boards use the male version DF9-51P-1V(69) and Xplained Pro extension boards use the female counterpart
DF9-51S-1V(69). This header has a standardized pin-out as shown in
extension connector
Note
All pins are not connected on all Xplained Pro MCU boards, how many pins that are used depend
on how many segments and common terminals the target MCU supports.
Table 3.5. Xplained Pro segment LCD extension connector definition
Description
Common terminal 3
Name
ID
GND
ADC(+)
ADC(-)
GPIO1
GPIO2
PWM(+)
PWM(-)
IRQ/GPIO
SPI_SS_B/GPIO
TWI_SDA
TWI_SCL
USART_RX
USART_TX
SPI_SS_A
SPI_MOSI
SPI_MISO
SPI_SCK
GND
VCC
definition".
Function
COM3
Description
Communication line to the ID chip on extension board.
Ground
Analog to digital converter , alternatively positive part of dif-
ferential ADC
Analog to digital converter , alternatively negative part of dif-
ferential ADC
General purpose IO
General purpose IO
Pulse width modulation , alternatively positive part of differ-
ential PWM
Pulse width modulation , alternatively positive part of differ-
ential PWM
Interrupt request line and/or general purpose IO.
Slave select for SPI and/or general purpose IO.
Data line for two wire interface. Always implemented, bus
type.
Clock line for two wire interface. Always implemented, bus
type.
Receiver line of Universal Synchronous and Asynchronous
serial Receiver and Transmitter
Transmitter line of Universal Synchronous and Asynchro-
nous serial Receiver and Transmitter
Slave select for SPI. Should be unique if possible.
Master out slave in line of Serial peripheral interface. Always
implemented, bus type
Master in slave out line of Serial peripheral interface. Always
implemented, bus type
Clock for Serial peripheral interface. Always implemented,
bus type
Ground
Power for extension board
Table 3.5, "Xplained Pro segment LCD
Pin Pin Function
1 2 COM2
Atmel SAM4L Xplained Pro [USER GUIDE]
Description
Common terminal 2
42074A-MCU-02/13
9
