2.

Getting Started

2.1

Quick-start

3 Steps to start exploring the Atmel Xplained Pro Platform
● Download and install
● Launch Atmel Studio
● Connect a Micro-B cable to the DEBUG USB port
2.2

Connecting the Kit

When connecting Atmel SAM4E Xplained Pro to your computer for the first time, the operating system will do a
driver software installation. The driver file supports both 32-bit and 64-bit versions of Microsoft
and Windows 7.
Once connected the green power LED will be lit and Atmel Studio will autodetect which Xplained Pro
evaluation- and extension kit(s) that's connected. You'll be presented with relevant information like datasheets
and kit documentation. You also have the option to launch Atmel Software Framework (ASF) example
applications. The target device is programmed and debugged by the on-board Embedded Debugger and
no external programmer or debugger tool is needed. Refer to the
regarding how to compile and program the kit.
2.3

Design Documentation and Related Links

The following list contains links to the most relevant documents and software for SAM4E Xplained Pro.
Xplained Pro products
1.
for 8- and 32-bit Atmel microcontrollers. It consists of a series of low cost MCU boards for evaluation and
demonstration of features and capabilities of different MCU families.
2. SAM4E Xplained Pro User Guide
3. SAM4E Xplained Pro Design Documentation
drawings, 3D plots, layer plots etc.
4. EDBG User Guide
Atmel Studio
5.
microcontrollers.
6.
IAR Embedded Workbench
There is a 30 day evaluation version as well as a code size limited kick-start version available from their
website. The code size limit is 16KB for devices with M0, M0+ and M1 cores and 32KB for devices with
other cores.
7. Atmel sample store
1
http://www.atmel.com/atmelstudio
2
http://www.atmel.com/atmelstudio
3
http://www.atmel.com/XplainedPro
4
http://www.atmel.com/Images/Atmel-42216-SAM4E-Xplained-Pro_User-Guide.pdf
5
http://www.atmel.com/Images/Atmel-42216-SAM4E-Xplained-Pro_User-Guide.zip
6
http://www.atmel.com/Images/Atmel-42096-Microcontrollers-Embedded-Debugger_User-Guide.pdf
7
http://www.atmel.com/atmelstudio
8
http://www.iar.com/en/Products/IAR-Embedded-Workbench/ARM/
9
http://www.atmel.com/system/samplesstore
1
Atmel Studio
3
- Atmel Xplained Pro is a series of small-sized and easy-to-use evaluation kits
4
- PDF version of this User Guide.
6
- User guide containing more information about the onboard Embedded Debugger.
7
- Free Atmel IDE for development of C/C++ and assembler code for Atmel
® 8 ®
for ARM
9
- Atmel sample store where you can order samples of devices.
Atmel Studio user guide
5
- Package containing schematics, BOM, assembly
. This is a commercial C/C++ compiler that is available for ARM.
Atmel SAM4E Xplained Pro [USER GUIDE]
® ®
Windows XP
2
for information
5
42216A-MCU-01/2014
