Xplained Pro Lcd Extension Connector - Atmel SAM4E Xplained Pro User Manual

Pin number
17
18
19
20
3.4.2.

Xplained Pro LCD Extension Connector

The LCD connector provides the ability to connect to display extensions that have a parallel interface.
The connector implements signals for a MCU parallel bus interface and a LCD controller interface as well
as signals for a touch controller. The connector pin-out definition is shown in
Connector on page 10. Note that usually only one display interface is implemented, either the LCD
controller or the MCU bus interface.
A FPC/FFC connector with 50 pins and 0.5mm pitch is used for the LCD connector. The connector
XF2M-5015-1A from Omron is used on several Xplained Pro designs and can be used as a reference.
Table 3-5 Xplained Pro LCD Connector
Pin number Name
1 ID
2 GND
3 D0
4 D1
5 D2
6 D3
7 GND
8 D4
9 D5
10 D6
11 D7
12 GND
13 D8
14 D9
15 D10
16 D11
17 GND
18 D12
19 D13
Name Description
SPI_MISO Master in slave out line of serial peripheral interface. Always
implemented, bus type.
SPI_SCK Clock for serial peripheral interface. Always implemented, bus type.
GND Ground
VCC Power for extension board
RGB interface description
Communication line to the ID chip on an extension board
Ground
Data line
Data line
Data line
Data line
Ground
Data line
Data line
Data line
Data line
Ground
Data line
Data line
Data line
Data line
Ground
Data line
Data line
Table 3-5 Xplained Pro LCD
MCU interface description
Atmel SAM4E Xplained Pro [USER GUIDE]
Atmel-42216B-SAM4E-Xplained-Pro_User Guide-09/2015
10
