Chapter 03
3-1. How to Reconfigure OSD (On-Screen Display) Menu
• 1. Press the MENU button to activate the OSD menu.
+/ -
• 2. Press the button to toggle between options in the menu. As you move from one icon to
another, the option item is highlighted.
• 3. To select the highlighted item on the menu press the button MENU.
+/-
• 4. Press the button to select the parameter.
• 5. Press the button MENU to enter the slide bar and then use the +/- button to make your changes,
according to the indicators on the menu.
• 6. Press the AUTO to save the setting and return to the previous menu. If you want to adjust any
other functions, repeat steps 2-5.

3-2. OSD Function Introduction

Colour
OSD
ther
• Contrast: Controls the contrast of picture displayed. The adjusting range is from 0 to 100.
• Brightness: Controls the brightness of picture displayed. The adjusting range is from 0 to 100.
• Colour Temp: Controls the screen colour temperature of 6500K/9300K/User*.
• Colour Adjust: Use +/- to adjust the R/G/B value.
Screen Setup
Col ou r C o n t r a s t
Pic tu re B r i g h t n e s s
Fun ct ion C o l o u r T e m p
OSD M enu
C o l o u r A d j u s t
Mis c
E x i t
Exi t
2 5 6 0 x 1 6 0 0 5 9 . 8 H z
5 0 -
5 0 -
9 3 0 0 K 6 5 0 0 K
