- Page 1 ELECROW ELECROW 7 Inch HDMI Touchscreen Monitor Model: RC070N USER MANUAL Customer Support: Should there be any questions, please feel free to let us know and contact us with your purchase order number at info@elecrow.com.
-
Page 2: Table Of Contents
2-1-3. Connect the Monitor to Raspberry Pi and Power the Raspberry Pi 2-2. Connected to PC/Laptop (with HDMI Port) Chapter 03: Troubleshooting Guide and Warranty 3-1. Troubleshooting Guide 3-2. Warranty 3-3. Custormer Support Chapter 04: Specifications © 2019 ELECROW All Rights Reserved. -
Page 3: Chapter 01 Before Using The Product
1 x HDMI to MINI HDMI Cable (for connecting PC) • 4 x M2.5 Screws (to mount RPI) • 4 x Small Copper Pillars (to support RPI) • 2 x Speakers • 1 x User Manual 1-2. Product Description 2019 ELECROW All Rights Reserved. ©... -
Page 4: Port Description
4 MINI HDMI Interface (Display): Connects to a source device by using an HDMI cable. ○ ○ 5 & 6 Speaker: Connects to the speaker. ○ ○ ○ ○ ○ 7 & 8 & 9 & 10 & 11 : For backlight & volume adjustment and power on/off. © 2019 ELECROW All Rights Reserved. -
Page 5: Connected To Raspberry Pi
2-1-2. How to Use with Raspbian/ Ubuntu Mate/ Retropie/ Kali System Step 1. Download the Image Raspbian Image ① Image download Link: https://www.raspberrypi.org/downloads/raspbian/ User: pi Password: raspberry Please download the latest Image for Raspberry Pi 4B Ubuntu Mate Image ② Image download Link: https://ubuntu-mate.org/download/#xenial © 2019 ELECROW All Rights Reserved. - Page 6 Retropie Image ③ Image download Link: https://retropie.org.uk/download/ Kali Image ④ Image download Link: https://www.offensive-security.com/kali-linux-arm-images/ User: root Password: toor © 2019 ELECROW All Rights Reserved.
- Page 7 1024 600 60 6 0 0 0 hdmi_drive=2 Please commend out by adding # in the front of "dtoverlay = vc4-fkms-V3D" or delete this line in the config.txt file when working with Raspberry Pi 4. © 2019 ELECROW All Rights Reserved.
-
Page 8: Connect The Monitor To Raspberry Pi And Power The Raspberry Pi
2-1-3. Connect the Monitor to Raspberry Pi and Power the Raspberry Pi • Monitor Connected to Raspberry Pi 4B 1. Install the small copper pillars onto the mounting holes. 2.Mount the Raspberry Pi on the back of the screen with M2.5 screws. © 2019 ELECROW All Rights Reserved. - Page 9 © 2019 ELECROW All Rights Reserved.
- Page 10 3. When the speakers are turned on 80% or more, it is recommended to connect the power port (not touch port) to provide full power. © 2019 ELECROW All Rights Reserved.
-
Page 11: Connected To Pc/Laptop (With Hdmi Port)
Note: Please note that when the monitor is connected to a game device or the monitor's touch end is connected to a power source, socket, or other power supply device, the touchscreen doesn’t work. 2019 ELECROW All Rights Reserved. ©... -
Page 12: Chapter 03: Troubleshooting Guide And Warranty
Considering the power supply voltage, we limit the maximum volume, so the sound is not so loud. If you need a loud volume in some situations, it’s The volume is too small recommended that you can connect an external mini speaker to amplify the sound. © 2019 ELECROW All Rights Reserved. -
Page 13: Warranty
3-2. Warranty • ELECROW Monitors carry a one (1) year limited warranty from the purchase date. In order to receive warranty service, proof of purchase of the ELECROW product is required. To obtain warranty service, please contact Customer Support. • This limited warranty does not cover for: Improper installation or maintenance;...
