Elecrow RC070S User Manual

7 inch hdmi touchscreen monitor

Advertisement

ELECROW 7 Inch HDMI
Touchscreen Monitor
Model: RC070S
USER MANUAL
Customer Support:
Should there be any questions, please feel free to let us know and contact us with
info@elecrow.com .
your purchase order number at

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RC070S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Elecrow RC070S

  • Page 1 ELECROW 7 Inch HDMI Touchscreen Monitor Model: RC070S USER MANUAL Customer Support: Should there be any questions, please feel free to let us know and contact us with info@elecrow.com . your purchase order number at...
  • Page 2: Table Of Contents

    2-1-3. Connect the Monitor to Raspberry Pi and Power the Raspberry Pi 2-2. Connected to PC/Laptop (with HDMI Port) Chapter 03: Troubleshooting Guide and Warranty 3-1. Troubleshooting Guide 3-2. Warranty 3-3. Custormer Support Chapter 04: Specifications 2019 ELECROW All Rights Reserved.
  • Page 3: Chapter 01 Before Using The Product

    • 4 x M2.5 Screws (to mount RPI) • 4 x Small Copper Pillars (to support RPI) • 2 x Pro Stand • 2 x M3 Screws (to mount Stand) • 2 x Speakers • 1 x User Manual 1-2. Product Description 2019 ELECROW All Rights Reserved.
  • Page 4: Port Description

    HDMI Interface (Display): Connects to a source device by using an HDMI cable/ connector. Speaker: Set up the speaker. Fan: Set up the fan device. Backlight&Volume: For backlight & volume adjustment. Earphone: For audio output. 2019 ELECROW All Rights Reserved.
  • Page 5: Chapter 02: Connecting And Using A Source Device

    • Raspbian Image Image Download Link: https://www.raspberrypi.org/downloads/raspbian/ User: pi Password: raspberry Please download the latest Image for Raspberry Pi 4B • Ubuntu Mate Image Image Download Link: https://ubuntu-mate.org/download/#xenial Click here Click here Download this Image and unzip 2019 ELECROW All Rights Reserved.
  • Page 6 Insert the TF card into the card reader → insert the card reader into the computer → open the SDFormatter software → select the memory card → click Format → pop up the box and click “Yes” or “OK” until the format succeeded 2019 ELECROW All Rights Reserved.
  • Page 7 Please commend out by adding # in the front of "dtoverlay = vc4-fkms-V3D" or delete this line in the config.txt file when working with Raspberry Pi 4. Step 5. Insert the SD Card into the Slot on the Back of the Raspberry Pi Motherboard. 2019 ELECROW All Rights Reserved.
  • Page 8: Connect The Monitor To Raspberry Pi And Power The Raspberry Pi

    • Monitor Connected to Raspberry Pi 4B 1. Peel off the stickers of the mounting holes, then install the small copper pillars onto them. 2. Mount the Raspberry Pi on the back of the screen with M2.5 screws. 2019 ELECROW All Rights Reserved.
  • Page 9 • Raspberry Pi 4 HDMI to Micro HDMI Connector USB Connector 4. Set up the speakers.(Please plug in the cable, then remove the sticker on the back of the speaker, and then paste the speaker on the screen.) 2019 ELECROW All Rights Reserved.
  • Page 10: Connected To Pc/Laptop (With Hdmi Port)

    Micro USB (Touch/Power) Note: Please note that when the monitor is connected to a game device or the monitor's touch end is connected to a power source, socket, or other power supply device, the touchscreen doesn’t work. 2019 ELECROW All Rights Reserved.
  • Page 11: Chapter 03: Troubleshooting Guide And Warranty

    4. Enter the following command to restart the Raspberry Pi for the with Raspberry Pi configuration file to take effect: sudo reboot. 5. Then you successfully set the sound to be output from the screen via HDMI. 2019 ELECROW All Rights Reserved.
  • Page 12: Warranty

    3-2. Warranty • ELECROW Monitors carry a one (1) year limited warranty from the purchase date. In order to receive warranty service, proof of purchase of the ELECROW product is required. To obtain warranty service, please contact Customer Support. • This limited warranty does not cover for: Improper installation or maintenance;...
